A novel constructed SPT15 mutagenesis library of Saccharomyces cerevisiae by using gTME technique for enhanced ethanol production

  • Ashraf A. M. M. El-Rotail1, 2,
  • Liang Zhang1,
  • Youran Li1,
  • Shuang Ping Liu1 and
  • Gui Yang Shi1Email author
AMB Express20177:111

https://doi.org/10.1186/s13568-017-0400-7

Received: 29 March 2017

Accepted: 4 May 2017

Published: 2 June 2017

Abstract

During the last few years, the global transcription machinery engineering (gTME) technique has gained more attention as an effective approach for the construction of novel mutants. Genetic strategies (molecular biology methods) were utilized to get mutational for both genes (SPT15 and TAF23) basically existed in the Saccharomyces cerevisiae genome via screening the gTME approach in order to obtain a new mutant S. cerevisiae diploid strain. The vector pYX212 was utilized to transform these genes into the control diploid strain S. cerevisiae through the process of mating between haploids control strains S. cerevisiae (MAT-a [CICC 1374]) and (MAT-α [CICC 31144]), by using the oligonucleotide primers SPT15-EcoRI-FW/SPT15-SalI-RV and TAF23-SalI-FW/TAF23-NheI-RV, respectively. The resultant mutants were examined for a series of stability tests. This study showed how strong the effect of using strategic gTME with the importance of the modification we conducted in Error Prone PCR protocol by increasing MnCl2 concentration instead of MgCl2. More than ninety mutants we obtained in this study were distinguished by a high level production of bio-ethanol as compared to the diploid control strain.

Keywords

Bioethanol Error-prone PCR Ethanol production Ethanol tolerance Global transcription machinery engineering SPT15

Introduction

Ethanol (ETOH) is a colorless liquid produced by the fermentation of sugars by a variety of microbes such as Saccharomyces cerevisiae (S. cerevisiae), Escherichia coli (E. coli), Klebsiella oxytoca and Zymomonas mobilis (Tan et al. 2016). It is used as fuel, solvent, sterilizer, antiseptic for wounds, cosmetics and pharmaceutical industry. S. cerevisiae has been studied extensively as a model organism among eukaryotes (Botstein and Fink 1988). The requirements of S. cerevisiae to produce a high level of ethanol are its ability to withstand an elevated concentration of ethanol and sugar existed in the fermentation medium (Hou 2009).

Recently, the global transcription machinery engineering (gTME) has been applied as an effective technique to enhance the target specific phenotype of microbes (Alper et al. 2006). The gTME uses molecular biology methods such as Error-prone polymerase chain reaction (Ep-PCR), DNA shuffling, etc. to construct an initial transcription factor and screen the target phenotype to obtain the enhanced metabolic flux or bacteria with a specific phenotype. Ep-PCR is a fast and cheap molecular biology method for random mutation in a particular piece of DNA. This technique is a based on PCR and its reaction mixture composition. Upon replication in EP-PCR, Taq polymerase is modulated by alteration of the composition of the reaction buffer usually by adjusting Mg and Mn ions as well as dNTPs in the PCR reaction. In this condition, the Taq polymerase, which lack DNA proof-reading property, introduces errors in a newly synthesized DNA during base pairing. The control of PCR reaction composition regulates the frequency of mis-incorporation of nucleotide bases into the sequence. In some directed evolution experiments, a high number of mutations around 9–12 bp/kb may be obtained (Cadwell and Joyce 1992). Therefore, cloning of the resulted PCR fragment or screened libraries of mutants provide proteins with desired activity (McCullum et al. 2010; Drummond et al. 2005). It produces most of the functional genes; however RNA polymerase II transcription efficiency is determined by initiation of transcription factors and promoter binding protein, and one of the first transcription factors in S. cerevisiae is TATA-binding protein (TBP). The SPT15 regulates the expression of most of all those genes, and essentially its variants modulate many genes those are necessary for ethanol tolerance. Previous research showed that variants of the S. cerevisiae TBP SPT15 could improve the yield of ethanol (Tan et al. 2016) by using the gTME (Alper et al. 2006).

The protocols established by (Cadwell and Joyce 1992; Alper et al. 2006) were adopted on our study with some modification in the process of polymerase chain reaction (PCR) protocol. Different concentrations of MnCl2 were used instead of MgCl2 to produce mutations in the sequence of SPT15 and TAF23 genes by using the Ep-PCR amplification process. This approach was satisfactorily applied to get mutants by which it would be able to improve ethanol production and ethanol tolerance.

Materials and methods

Microbial strains and culture media

Escherichia coli JM109 was used as a host for plasmid construction. It was grown in Luria–Bertani (LB) medium containing 5 g/L yeast extract, 10 g/L Bacto-peptone and 10 g/L (NaCl) and cultured at 37 °C. Super optimal broth (SOB) containing 5 g/L yeast extract, 20 g/L Bacto-peptone, 0.95 g/L (MgCl2), 0.186 g/L (KCl) and 0.5 g/L (NaCl) was used before spreading on solid media after transformation. S. cerevisiae strain was used for genetic manipulation and cultured in Basic medium-Bacto-peptone glucose broth (YPD) medium; this medium was used for routine growth of yeast strains at 30 °C and contained 10 g/L yeast extract, 20 g/L Bacto-peptone and 20 g/L glucose. Solid media contained 2% agar for both types of mediums. Respective antibiotics [ampicillin (Amp) 100 mg/L; kanamycin (Kan) 35 mg/L] were added to maintain the plasmids (Liu et al. 2014). For screening, the medium (YPDG) containing 10 g/L yeast extract, 20 g/L Bacto-peptone, 20 g/L glucose and resistance gene Glycosid-418 (G418) that used with the final concentrations (250 and 350 µg/mL), respectively (Wang et al. 2004). The Fermentation medium (YPDT) was contained 10 g/L yeast extract, 20 g/L Bacto-peptone, 20 g/L glucose and 0.2 g/L Thiamine.

Genetic manipulation strain

Saccharomyces cerevisiae eukaryotic system containing the non-mutant genes chromosomal copy of SPT15 and TAF23 genes was selected. Table 1 shows that two haploids types of industrial ethanol-producing yeast (MAT-a/MAT-α) were mated and genetically manipulated in this study, as well Table 2 shows that oligonucleotide primers (MAT-F), (MAT-a) and (MAT-alpha) were used in order to obtain a strain possessing diploid genetic traits, named as S. cerevisiae R-control. The protocol of Hoffman and Winston (1987) was used to extract genomic DNA (gDNA) with slight modifications by using Mini-DNA fragment Rapid Kit (BioSCi Biotech Co., LTD, Hangzhou, China).
Table 1

Microbial strains and plasmids used

Strains/plasmids

Relevant characteristics

Source of reference

Strains

 S. cerevisiae haploid strain

Wild-type (MAT- α) CICC 1374

China center of industrial culture collection (CICC)

 S. cerevisiae haploid strain

Wild-type (MAT- a) CICC 31144

 S. cerevisiae R-control

Diploid strain

This study

 E. coli JM109

recA1 supE44 endA1 hsdR17 gyrA96 relA1 thi (Lac-proAB) F’[traD36 proAB + lacI q lacZM15]

Stratagene

Plasmids

 pMD19-T vector

Amp r clone vector

TaKaRa, Japan

 pYX212

Amp r TPI promoter

This study

 pYX212-kan-SPT15-Mu

pYX212 with SPT15 mutant gene

This study

 pYX212-kan-TAF23-Mu

pYX212 with TAF23 mutant gene

This study

Amp r: ampicillin resistant, Kan: kanamycin

Table 2

The oligonucleotide primers used

Primer names

Sequence (5′–3′)a

SPT15-EcoRI-FW

CCGGAATTCATGGCCGATGAGGAACGTTTAAAGG

SPT15-SalI-RV

CGCTAGGTCGACTCACATTTTTCTAAATTCACTTAGCACA

TAF23-NheI-RV

ACTCGAGCTAGCCTAACGATAAAAGTCTGGGCGACCT

TAF23-SalI-FW

CGCTAGGTCGACATGGATTTTGAGGAAGATTACGAT

pYX212-FW

GGGCAGCATAATTTAGGAG

pYX212-RV

AGGGATGTAT CGGTCAGTCA

425-TT-BamHI-FW

CGCGGATCCATCCGTATGATGTGCCTGACTA

426-TT-EcoRV-RV

AATAAGATATCAGGGAAGAAAGCGAAAGGAG

(MAT-F)

AGTCACATCAAGATCGTTTATGG

(MAT-a)

ACTCCACTTCAAGTAAGAGTTTG

(MAT-alpha)

GCACGGAATATGGGACTACTTCG

aRestriction sites are in italic and underlined

Target genes

TATA-binding protein subunit of transcription factor complexes Transcription factor II D (TFIID) and Transcription factor II B (TFIIB) were used (Cormack and Struhl 1992). It plays an enormous role during gene expression in yeast cells (Hampsey 1998). Additionally, much gene regulation takes place by targeting TBP with coactivators and corepressors, which interact with TBP for gene transcription (Lewis and Reinberg 2003). Mutations in the TBP confer enhanced tolerance to stress in S. cerevisiae of ethanol and glucose (Lee and Young 1998). The SPT15 and TAF23 were used in this study to improve cellular phenotype for yeast strain with ethanol tolerance. Both genes express via transcription during RNA polymerase II coupled with the association of TBP with general transcription factors and regulators (Alper and Stephanopoulos 2007; Gietz and Woods 2006; Jungwoo et al. 2011).

Extraction, cloning and overexpression of the target genes

The extracted amount of gDNA was used as a template with sequence-specific primers mentioned below in Table 2 to begin the process of cloning of SPT15 and TAF23 genes in this study. Standard methods were used for PCR amplification, analysis of DNA fragments and electroporation as directed by Green and Sambrook (2012). The extension reaction was adjusted on 72 °C for 10 min. In addition to, the annealing temperature was changed it to 58, 55 °C for SPT15 and TAF23 genes, respectively. The PCR and Ep-PCR experiments were performed by using the Real-Time PCR Detection System with software CFX Manager 3.0 (Bio-Rad, USA), using rTaq DNA polymerase (TaKaRa, Japan). All PCR products were sequenced to verify the mutation rate for all the new mutations and to get the mutant genes sequence for SPT15-Mu and TAF23-Mu.

This was followed by cloning and transformation and then plated the ligation product on specific antibiotic-containing medium. The plasmid(s) and gene(s) verification was done by Sangon Biotech CO., LTD, Shanghai, China.

Design of primers and vectors

Plasmid design with target genes

The oligonucleotide primers SPT15-EcoRI-FW/SPT15-SalI-RV and TAF23-SalI-FW/TAF23-NheI-RV were designed as primers for SPT15 and TAF23 genes, respectively. The genome sequence of S. cerevisiae and both genes sequences were searched using the S. cerevisiae Genome Database and the National Center for Biotechnology Information. All the target genes were PCR amplified from the gDNA of S. cerevisiae R-control as a template using oligonucleotide primers SPT15-EcoRI-FW/SPT15-SalI-RV and TAF23-SalI-FW/TAF23-NheI-RV, respectively as referred in Table 2. The resulting PCR products were purified by Mini-DNA fragment Rapid Kit and the target genes were ligated with vector (pYX212) which formed two plasmids pYX212-Amp-SPT15 and pYX212-Amp-TAF23. Both plasmids were individually transformed into E. coli JM109 competent cells for multiplication on SOB medium with Amp (100 μg/mL) at 37 °C for 24 h. Then, these plasmids (pYX212-Amp-SPT15 and pYX212-Amp-TAF23) were extracted and purified by using a Plasmid Mini-Preps Kit (BioSCi Biotech Co., LTD, Hangzhou, China). These genes obtained from the previous step were used as a template to initiate DNA amplification using Ep-PCR technique for the next steps and preserved in pMD19-T vector.

Plasmid design with mutant genes

The pYX212-TPI plasmid was designed as an expression vector; designed as bacterial and yeast expressing system. For this plasmid, the prokaryotic and eukaryotic selection markers are Amp, uracil and Kan as shown in Fig. 1. Oligonucleotide primers were designed based on the pYX212 vector, with restriction sites EcoRI and SalI for SPT15 gene mutagenesis; moreover SalI and NheI were used for TAF23. For plasmid construction, overexpression of genes and electroporation, standard methods were applied as directed (Green and Sambrook 2012; Lee et al. 2007) (Table 2).
Fig. 1

The physical maps of recombinant plasmids. a The pYX212-kan (empty vector). b, c The pYX212 with SPT15-Mu and TAF23-Mu, respectively. The genes are under the R-control of TPI promoter and terminator with EcoRI and SalI restriction sites for SPT15 and SalI and NheI restriction sites for TAF23; (Ampr) ampicillin resistance gene; (Kanr) Kanamycin resistance gene; (G418) resistance gene

Both SPT15 and TAF23 genes were randomly mutated, amplified by standard PCR and ligated individually with pYX212 plasmid. The fragment of SPT15 mutant gene and pYX212 plasmid were digested with EcoRI and SalI, however the pYX212 plasmid and TAF23 gene were digested by using restriction enzymes SalI/NheI and ligated by using T4 DNA Ligase (Thermo Scientific CO., LTD, Meridian, USA) to get pYX212-kan-SPT15-Mutant (pYX212-kan-SPT15-Mu) and pYX212-kan-TAF23-Mutant (pYX212-kan-TAF23-Mu) plasmids, respectively.

Construction of mutant genes libraries

The gTME strategy and Ep-PCR were used to express SPT15 and TAF23 genes encoding TBP. They are commonly used method to give the irregular variations of mutations into a defined segment and specific of the DNA (Hou et al. 2015). Those approaches are based on the amplification of the entire gene(s) using primers that possess the region of interest (Hemsley et al. 1989). Those techniques were used to create randomized genomic libraries by working on the principle r-Taq polymerase that can anneal incompatible base pairs (bp) during PCR (Drummond et al. 2005; McCullum et al. 2010). The latter produced the largest possible number of changes in the gene sequence (low, medium and high) with strong and stable rate of mutation(s). The procedure was adjusted by adding 1–30 μL of MnCl2 (5 mM), and mixed with dNTPs one by one and retain 22 μL of MgCl2 (25 mM) within 100 μL Ep-PCR reaction mixture.

Accordingly, this modification allowed initiating DNA amplification beginning with small amounts of original molecule to bring to considerable amounts of a high random mutagenesis. Then, the library of mutations was constructed with that combination of genes SPT15-Mu and TAF23-Mu. The aforesaid mutations were inserted into the strain by using pYX212 vector. The new mutations could induce the production of ethanol at high rate which is expected to be higher than the R-control strain.

The mutagenic reaction mixture contained different amount of MnCl2 (1, 3, 5, 10, 20 and 30 μL) (5 mM), 22 μL of MgCl2 (25 mM), 10 µL of (10× Taq Buffer), 1 µL (each) PCR primers (mentioned above in Table 2), 1 µL of Template gDNA, 1 µL rTaq DNA polymerase, 10 µL of (10× dNTP Mix), then fulfill the volume mixture to 100 µL of distilled water. The (10× dNTP Mix) mixture was prepared by using an equal dNTP concentrations as follows: 2 µL of dATP (0.2 mM), 2 µL of dGTP (0.2 mM), 10 µL dCTP (1 mM), 10 µL dTTP (1 mM) and the distilled water was added until the volume of 100 µL. The dGTP, dNTP, dCTP, dTTP, and rTaq DNA polymerase enzymes were purchased from TaKaRa, Japan.

Transformation for SPT15-Mu and TAF23-Mu genes into S. cerevisiae

High-efficiency yeast transformation procedure was determined according to the methods of Gietz (2014) and Gietz and Woods (2006), with some modifications. Briefly, each 50 μL plasmid harboring DNA mutant gene was added individually to a tube. Then the mixture was filled up to 380 μL alongside by using transformation mixture [240 µL PEG (50%), 36 µL LiAc (1 M), 50 µL ssDNA (2 mg/mL), 54 µL sterile distilled water]. total mixture was subsequently heated shockingly at 42 °C for 25 min. Cells were harvested by centrifugation at 2.4g for 2 min at room temperature, re-suspended in 1 mL sterile water, then mixed by inverting the tube up and down. 100 µL of the suspension was plated on agar medium containing G418 (100 µg/mL). The plates were incubated at 30 °C for 2 days for growth.

Study of mutations characteristics

Mutations stability

Ten colonies were selected for the screening as a random mutation. In order to ensure the stability test of each colony, 100 µL was plated on YPD solid medium in triplicate with different concentration of Kan. The colony that has a good viability among the grown colonies was then transferred on YPD containing G418 (250 µg/mL) and incubated at 30 °C until single colonies appeared. By the unaided eye, the best five colonies were picked up after photographed the plates. Subsequently, re-grown on a fresh YPDG medium containing G418 (350 µg/mL); then incubated at 30 °C for 2 days. Afterward, the resistant colonies were streaked out (Guo et al. 2011; Zhang et al. 2011). Finally, colony PCR reaction was performed to verify the success of the mutations by using oligonucleotide primers 425-TT-BamHI-FW/426-TT-EcoRV-RV as referred in Table 2. The PCR products were loaded on 1.5% Agarose and visualized to make sure the criteria of the stab le genes selection.

Ethanol tolerance of mutant strains

Ethanol tolerance test was used in order to assay the ability of the 102 mutations that harboring SPT15 genes. It was carried out by spot assay in duplicate onto YPD plates containing Kan within various concentrations of ethanol 1, 3, 5, 7, 10 and 15% (v/v), respectively. The colonies forming ability and viability on a high level of ethanol were monitored after incubation at 30 °C for 3 days (Kasavi et al. 2014).

Effect of ethanol concentration on the growth rate of mutant strains

The ethanol tolerance of the SPT15 mutants and S. cerevisiae R-control strains were grown in 24 deep holes microplate containing 5 mL YPD medium in the absence of ethanol in each hole, as a primary pre-culture to grow the strains. The OD595 was reached 0.05, then 40 µL of the pre-cultures from SPT15 mutants and R-control strain were inoculated into 24 deep holes microplate containing 3 mL liquid fresh medium present/absent of G418 (250 µg/mL). In this estimation, five various concentration of ethanol 0, 1, 3, 5 and 7% (v/v) were used for each treatment. Finally, mutants and R-control strain growth rate were monitored by measuring dry cell weight (DCW) and OD595 values. Microplate reader (EZ Read 800, Biochrom Ltd., Cambridge, UK), with Galapagos Exert Software (Version 1.1) were used to recording OD595 values.

Measurement of the ethanol and glucose yield

Fermentation conditions

Fermentation was carried out in the cap-covered flasks (500 mL) containing 50 mL YPDT medium as followed: 20 g/L glucose, 10 g/L yeast extract, 20 g/L Bacto-peptone and 0.2 g/L thiamine (vitamin B1) (Kotarska et al. 2006; Xu et al. 2012), and 5 mL of inoculum were added. The mixture was cultured at 30 °C and 200 rpm till OD595 reached 1.

High performance liquid chromatography analysis

The broth samples were centrifuged at 1g for 20 min then filtered through a 0.22 μm filter (Whatman® Spartan® HPLC certified syringe filters, sterile, diam. 13 mm). The supernatant was appropriately diluted by 10% of Trichloro acetic acid (TDA) (1:1) for the product analysis. The concentrations of the samples were estimated by high performance liquid chromatography (HPLC) analysis, with a Shodex RI SUGER SH-1011 HPLC column (7 µm, 8 I.D. × 300 mm) (Showa Denko Co., Ltd., K.K., Japan). The column temperature was heated at 50 °C with 0.01 M H2SO4 as a mobile phase and flow rate was 0.8 mL/min. The concentrations were subsequently detected with a refractive index detector with 285 nm wave length (HITACHI High Technologies Co., Ltd., Tokyo, Japan) Model (CM 5110/5210/5310/5430/5450) to estimate the percentage of both glucose and ethanol in the samples. The HPLC analysis was performed by isocratic condition using 1% Sulfuric acid in water (v/v) as mobile phase. The product was eluted around 22 min for total running time per sample. All HPLC data were analyzed with EZChrom Elite (Version 3.3.2) SP2 Chromatography Data System, Agilent Tech software. The percentage of the ethanol yield production between the mutant strains and R-control strain was estimated by using the following equation:
$$ IR = [(EP_{ 2} /EP_{ 1} )*100] - 100 $$

IR increase of rate, EP1: ethanol production for mutant strains, EP2: ethanol production for R-control strain.

Results

Hybridization, amplification and construction of plasmid

The colonies were chosen for mating process between the haploid strains of S. cerevisiae (MAT-a and MAT-α) for the industrial ethanol-producing yeast. Conjunction process resulted a strain of S. cerevisiae possessing diploid genetic traits, and was named S. cerevisiae R-control. The gDNA of S. cerevisiae R-control was used as a template for PCR reaction. The clear bands of 723 and 621 bp for SPT15 and TAF23 genes, respectively were identified. Construction and ligation of plasmid with genes have resulted in clear bands at 3323 and 3221 bp for pMD19-T-Amp-SPT15 and pMD19-T-Amp-TAF23, respectively.

Construction of mutant genes libraries

The Ep-PCR was applied using different concentrations of MnCl2 (1, 3, 10 and 20%) for the alteration of each gene sequence, and 150 mutants were obtained. Based on the highest rate of success in the mutation, 50 mutants were chosen for SPT15 and 6 mutants for TAF23. The chosen mutants were classified into three categories; (high, medium and low) based on the error rate (MER) according to the classification previously reported by Lanza and Alper (2011). Regarding the SPT15 gene, 27 mutant strains were identified as medium MER and 23 mutant strains as high MER. In contrast, 6 mutant strains as low MER were detected with TAF23 (Fig. 2a, b). All the strains have high similarity with the R-control strain which is at least >75%.
Fig. 2

a, b Summary of the mutation rate for SPT15 and TAF23 mutant genes

In details, by using 1% of MnCl2, 1 and 3 mutants with a medium and high MER, respectively were observed with SPT15; however 3 mutants with a low MER were observed with TAF23. Moreover, 3% of MnCl2 resulted in the construction of 5 and 9 mutants with a high and medium MER, respectively with SPT15. However 3 mutants with a low MER were constructed with TAF23 using the same concentration. Furthermore, 14 mutant strains with a high MER and 2 mutant strains with a medium MER were formed by using 10% of MnCl2 with SPT15. Finally, 15 mutant strains with a medium MER and 1 mutant strain with a high MER were resulted by using 20% of MnCl2. No mutants were formed with TAF23 by using both 10 and 20% of MnCl2.

Construction of pYX212-SPT15-Mu and pYX212-TAF23-Mu plasmids

Both SPT15-Mu and TAF23-Mu genes were ligated individually with pYX212 using T4 DNA ligase to construct vector pYX212 with SPT15 and TAF23, respectively. The resultants after ligation processes were named pYX212-SPT15-Mu and pYX212-TAF23-Mu, respectively. The gDNA S. cerevisiae R-control was used as a template for PCR reaction. The bands at 723 and 621 bp for SPT15 and TAF23 genes were identified, respectively after the plasmids were digested.

Study of the ethanol tolerance of mutant strains

Five replicates of TAF23 mutants were checked for the stability of G418 resistance gene, however they were not able to resist and to grow at the concentration 250 µg/mL of G418. In addition, 5 replicates of SPT15 mutations by a total number of 250 were selected, and their stability tests were examined. These mutations were subjected to G418 at two different concentrations, 250 and 350 µg/mL, respectively (Walker et al. 2003), to screen the strains harboring stable resistance genes. Subsequently, the Normal PCR was conducted for these strains in order to amplify the successful resistance genes with concentrations of G418 to identify the extent of their activities and the stability for those mutations. Afterthought, we were able to choose the best 102 mutants with SPT15 gene from the total selected 250 mutants. In addition, the total of 14, 24, 37 and 27 mutations were successfully chosen at 1, 3, 10 and 20% of MnCl2.

The ethanol tolerance test was used to investigate 102 selected mutants. After 72 h of incubation at 30 °C, the colony formation was monitored and recorded. The transported colonies of the new mutants SPT15 gene were compared to R-control strain that showed a slight improvement to form the colony on the media containing 1, 3, 5 and 7% (v/v) of ETOH. Conversely, the formation and composition of mutant colonies were weak in presence of 10% ETOH compared to the low concentrations. Meanwhile, the media containing 15% (v/v) of ETOH did not display any growth of colonies (Fig. 3).
Fig. 3

Susceptibility of ethanol tolerance of S. cerevisiae mutant strains with various levels of ethanol concentrations (0, 1, 3, 5, 7, 10 and 15%) on YPD media containing Kan. M1, M2, M3, M4, M5, M6, M7, M8, M9 and M10 refer to the numbering of mutations colonies; as follows: R-M20C1-P3, R-M16C4-P3, R-M4C1-P3, R-M12C4-P3, R-M18C4-P3, R-M5C1-P3, R-M3C49-P10, R-M18C5-P10, R-M17C4-P20 and R-M9C2-P20, respectively

Effect of ethanol concentration on the growth rate of mutant strains

Results confirm of 94 transformants the previously mentioned stability tests, as the better growth rate for these mutants were observed when compared to the R-control strain (Figs. 4, 5). This result indicated that mutations contained SPT15 genes possess the ability to grow coexisting with different concentrations of ethanol more than the R-control strain. Likewise, using a different concentration of MnCl2, the growth was better in the concentration of 3% followed by 10, 20 and 1%, respectively. It was shown that (R-M20C1-P3), (R-M16C4-P3), (R-M4C1-P3), (R-M12C4-P3), (R-M18C4-P3) and (R-M5C1-P3) recorded higher growth rates at 3% of MnCl2. As well, (R-M3C49-P10) and (R-M18C5-P10) were the highest growth mutants with MnCl2 10%. Moreover, using 20% of MnCl2, (R-M17C4-P20) and (R-M9C2-P20) reported higher growth rates.
Fig. 4

a Growth curve for the R-control strain and bg growth curves for the best mutant strains (R-M20C1, R-M16C4, R-M4C1, R-M12C4, R-M18C4 and R-M5C1) obtained by the Ep-PCR reaction by using 3% MnCl2 concentration, respectively. These strains were inoculated into the YPDT medium at different levels of ethanol concentrations ( ) 0% ETHO, ( ) 1% ETHO, ( ) 3% ETHO, ( ) 5% ETHO and ( ) 7% ETHO

Fig. 5

a Growth curve for the R-control strain and be growth curves for the best mutant strains (R-M3C49-P10, R-M18C5-P10, R-M17C4-P20 and R-M9C2-P20) obtained by the Ep-PCR reaction by using 10 and 20% MnCl2 concentrations, respectively. These strains were inoculated into the YPDT medium at different levels of ethanol concentrations ( ) 0% ETHO, ( ) 1% ETHO, ( ) 3% ETHO, ( ) 5% ETHO and ( ) 7% ETHO

In details, mutants of R-M12C4-P3 and R-M18C4-P3 recorded a higher growth of values for DCW, which reached to 2.01 g/L (DCW) however the R-control recorded 1.39 g/L (DCW) at concentration of 1% ethanol. Moreover, the growth of R-M18C4-P3 mutant recorded the values for (DCW) 1.88 g/L at 3% ethanol; however 1.25 g/L was recorded for the R-control. On the other hand, the concentrations 5 and 7% of ethanol showed better growth rate for all mutants than R-control strain (Figs. 4, 5).

Measurement of the ethanol and glucose yield

In order to estimate the efficiency of the different mutants for the production of ethanol, HPLC was used in this study. During the aerobic fermentation processes, the production of ethanol in the yeast expressing SPT15 increased more than 60%, moreover the glucose decreased to 0. 19 g/L compared to the R-control strain. With the addition of 3% MnCl2, all the mutants showed higher ethanol production from 14.11 to 15.72 g/L compared to the R-control which produced 9.8 g/L, and the other used mutants with 1, 10 and 20% concentrations of MnCl2. The yield of the R-M20C1-P3 mutant strain reported the highest ethanol production 15.72 g/L with a reduction in glucose content 0.47 g/L. The production of ethanol was higher than R-control by using 1% of MnCl2, however decreased compared to the other mutants.

It is worth mentioning that the SPT15 mutant library showed remarkable growth better than R-control strain in the presence of 1 and 3% ethanol with 20 g/L glucose. Consequently, the stress was increased to 7 and 10% ethanol in the subsequent serial sub-culturing. The reason for this phenomenon was speculated to be improved growth of all mutants due to their enhanced tolerance to ethanol stress, which was verified through higher mutants of cell density of R-M12C4-P3 and R-M18C4-P3 which recorded yield of 2.07 g/L (DCW) compare to R-control which was 1.99 g/L (DCW). This result was in accordance with previous results reported by Alper et al. (2006). Table 3 further summarizes results after anaerobic fermentation processes to make a comparison of parameters yields between the best mutant strains that obtained and R-control.
Table 3

Comparison of parameters yields of the best and highest mutant strains for ethanol production with R-control, during anaerobic fermentation in the presence of 20 g glucose/L

Strainsa

Parameters

Final DCW (g/L)

Residual GLC (g/L)

Ethanol production (g/L)

Increase (%)

YEG ETHO g/GLC g

YEF ETHO g/CDW g

R-control

1.991

1.400

9.814

0.527

4.927

R-M20C1-P3

2.040

2.350

15.722

+60.3

0.891

7.706

R-M16C4-P3

2.014

1.900

15.471

+57.7

0.855

7.679

R-M4C1-P3

2.032

1.900

15.470

+57.7

0.855

7.616

R-M12C4-P3

2.071

1.750

15.322

+56.2

0.839

7.402

R-M18C4-P3

2.070

2.050

15.290

+55.9

0.852

7.387

R-M5C1-P3

1.981

1.700

15.211

+55.1

0.831

7.680

R-M3C49-P10

2.011

1.900

14.036

+43.1

0.786

7.029

R-M18C5-P10

2.040

2.150

14.008

+42.8

0.785

6.861

R-M17C4-P20

1.984

2.050

13.486

+37.5

0.756

6.811

R-M9C2-P20

2.012

2.200

13.464

+37.2

0.761

6.724

P3: 3% of MnCl2, P10: 10% of MnCl2 and P20: 20% of MnCl2; that were used in the Ep-PCR reaction

CDW dry cell weight, GLC glucose, YEG yield of ETHO g/glucose used g, YEF yield of ETHO g/final CDW g

aIndicates to the highest mutant strains for ethanol production

Discussion

Up to the present time, the gTME technique has been used for the construction of new mutant; however in our study we processed a new yeast strain for a library of novel mutants by using SPT15 gene. Moreover, the gTME technique has been modified by using MnCl2 instead of the most applied mixture Ep-PCR reaction MgCl2. By using different concentrations of MnCl2 resulted in increasing the error rate throughout DNA synthesis (Pavlov et al. 2004). This modification by using this condition led to an excess of changes from)Adenine to Guanine) and (Thymine to Cytosine), which had been a significant impact on the error rate (Sinha and Haimes 1981).The frequency of mutation in Ep-PCR could be changed by adjusting PCR conditions that provided accessibility in operation for evolution experiments (Wang et al. 2006). The haploid wild-type strains of S. cerevisiae (MAT-a) and (MAT-α) have been mated to produce a new diploid strain of S. cerevisiae R-control. In the gTME technique, the TBP plays an important role in encoding with SPT15 and TAF23 genes in S. cerevisiae. The theoretical studies have supposed that TAF23 gene is critical to TBP interactions which might due to the presence of TAF23 gene series of helices and linkers (Luhe et al. 2011; Alper et al. 2006; Mal et al. 2004; Gegonne et al. 2001). Consequently, results yielded 6 mutations with TAF23-Mu gene and 50 mutations with SPT15-Mu gene.

The G418 resistance could simplify the selection of stable transfected cell lines that reflected the characteristics of pYX212-SPT15-Mu and pYX212-TAF23-Mu at the expression of the stabilized genes which were not lost over time. The higher concentrations of G418 (350 µg/mL) enhanced the stability of mutant colonies at adverse pressure conditions that produced higher copy of mutations number. These results are similar to the finding reported by Wang et al. (2004).

The influences of ethanol on the growth of the SPT15-Mu and R-control strains have been investigated through the OD and DCW measurements. They were shown that the growth of all mutants increased gradually with all the concentration of ethanol compare to R-control. Furthermore, SPT15 gene with the addition of thiamin 200 mg/L to the medium culture resulted in improving the alcoholic fermentation by enhancing the growth of yeast cells (Kotarska et al. 2006). In the same way, numerous proof-of-concept researchers have confirmed the increasing of cellular tolerances through increasing the production of ethanol and glucose (Liu et al. 2010; Tan et al. 2016). In order to SPT15 as an ensemble, it can provide increased stronger resistance to ethanol and glucose. In addition, SPT15 interacts with TBP to increase its efficient to the SAGA-dependent promoters of many genes (Bhaumik and Green 2002). In conclusion, the genetic results revealed that the gTME technique could be an effective approach for construction of novel mutants under various external stresses. The gTME technique to S. cerevisiae has been performed to adapt its attitude towards higher concentrations of ethanol. All the examined mutants showed much better tolerance toward ethanol stress as compared to the R-control. The mutants resulted by using 3% of MnCl2 in the process of Ep-PCR recorded the highest ethanol production. In a prospective study, we seek to establish a basis for future industrial applications, through integrating the SPT15 mutant alleles of two new mutant strains into the chromosomes, to enhance ethanol tolerance and survive with high concentration of ethanol in the media.

Abbreviations

gTME:

global transcription machinery engineering

E. coli

Escherichia coli

S. cerevisiae

Saccharomyces cerevisiae

VHG:

very high gravity

Amp:

ampicillin

Kan:

kanamycin

G418:

glycosid-418 resistance gene

LB:

luria–bertani medium

SOB:

super optimal broth medium

YPD:

bacto-peptone glucose broth medium

TBP:

TATA-binding protein

gDNA:

genomic DNA

OD:

optical density

FDB:

fast digest buffer

PCR:

polymerase chain reaction

Ep-PCR:

error prone polymerase chain reaction

MAT- α:

MAT-alpha

HPLC:

high performance liquid chromatography analysis

MCS:

mutant colonies which were selected

AM:

absent mutations

ETHO:

ethanol

GLC:

glucose

CDW:

dry cell weight

YEG:

yield of ethanol gram/glucose used gram

YEF:

yield of ETHO gram/final CDW gram

ERM:

error rate at mutants

Declarations

Authors’ contributions

AE implemented the conception and design of article besides the acquisition of the data; LZ carried out the critical revision of article for important intellectual content; YL presented the administrative, technical, and logistic support; SL analyzed and interpreted of the data; GS endorsed the final approval of article and funded the work. All authors read and approved the final manuscript.

Acknowledgements

We thank Zhu Linghuan, Gao Zhi, Hua Li, Wang Junhua, Bemena Leo Duick, Mukama Omar Abdelmoneim Ali, Ahmed Mousa, Sherif Abed, Amr Bakry, Marwan Rashed and Yang Sun for their valuable assistance and continued support during work.

Competing interests

The authors declare that they have no competing interests.

Availability of data and materials

The data supporting the conclusion of this article is included within the article.

Funding

This work was funded by Jiangsu Province Science Fund for Distinguished Young Scholars (BK20140002).

Publisher’s Note

Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Open AccessThis article is distributed under the terms of the Creative Commons Attribution 4.0 International License (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted use, distribution, and reproduction in any medium, provided you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made.

Authors’ Affiliations

(1)
The Key Laboratory of Industrial Biotechnology, Ministry of Education, National Engineering Laboratory for Cereal Fermentation Technology, School of Biotechnology, Jiangnan University
(2)
Faculty of Environmental Agricultural Science, El Arish University

References

  1. Alper H, Stephanopoulos G (2007) Global transcription machinery engineering: a new approach for improving cellular phenotype. Metab Eng 9:258–267View ArticlePubMedGoogle Scholar
  2. Alper H, Moxley J, Nevoigt E, Fink GR, Stephanopoulos G (2006) Engineering yeast transcription machinery for improved ethanol tolerance and production. Science 314:1565–1568View ArticlePubMedGoogle Scholar
  3. Bhaumik SR, Green MR (2002) Differential requirement of SAGA components for recruitment of TATA-box-binding protein to promoters in vivo. Mol Cell Biol 22:7365–7371View ArticlePubMedPubMed CentralGoogle Scholar
  4. Botstein D, Fink GR (1988) Yeast: an experimental organism for modern biology. Science 240:1439–1443View ArticlePubMedGoogle Scholar
  5. Cadwell RC, Joyce GF (1992) Randomization of genes by PCR mutagenesis. PCR Methods Appl 2:28–33View ArticlePubMedGoogle Scholar
  6. Cormack BP, Struhl K (1992) The TATA-binding protein is required for transcription by all three nuclear RNA polymerases in yeast cells. Cell 69:685–696View ArticlePubMedGoogle Scholar
  7. Drummond DA, Iverson BL, Georgiou G, Arnold FH (2005) Why high-error-rate random mutagenesis libraries are enriched in functional and improved proteins. J Mol Biol 350:806–816View ArticlePubMedGoogle Scholar
  8. Gegonne A, Weissman JD, Singer DS (2001) TAFII55 binding to TAFII250 inhibits its acetyltransferase activity. Proc Natl Acad Sci 98:12432–12437View ArticlePubMedPubMed CentralGoogle Scholar
  9. Gietz RD (2014) Yeast transformation by the LiAc/SS carrier DNA/PEG method (Clifton, NJ). Methods Mol Biol 1205:1–12View ArticlePubMedGoogle Scholar
  10. Gietz RD, Woods RA (2006) Yeast transformation by the LiAc/SS carrier DNA/PEG method (Clifton, NJ). Methods Mol Biol 313:107–120PubMedGoogle Scholar
  11. Green M, Sambrook J (2012) Molecular cloning: a laboratory manual. Cold Spring Harbor Press, Cold Spring HarborGoogle Scholar
  12. Guo ZP, Zhang L, Ding ZY, Wang ZX, Shi GY (2011) Improving ethanol productivity by modification of glycolytic redox factor generation in glycerol-3-phosphate dehydrogenase mutants of an industrial ethanol yeast. J Ind Microbiol Biotechnol 38:935–943View ArticlePubMedGoogle Scholar
  13. Hampsey M (1998) Molecular genetics of the RNA polymerase II general transcriptional machinery. Microbiol Mole Biol Rev 62:465–503Google Scholar
  14. Hemsley A, Arnheim N, Toney MD, Cortopassi G, Galas DJ (1989) A simple method for site-directed mutagenesis using the polymerase chain reaction. Nucleic Acids Res 17:6545–6551View ArticlePubMedPubMed CentralGoogle Scholar
  15. Hoffman CS, Winston F (1987) A ten-minute DNA preparation from yeast efficiently releases autonomous plasmids for transformation of Escherichia coli. Gene 57:267–272View ArticlePubMedGoogle Scholar
  16. Hou L (2009) Novel methods of genome shuffling in Saccharomyces cerevisiae. Biotechnol Lett 31:671–677View ArticlePubMedGoogle Scholar
  17. Hou LH, Meng M, Guo L, He JY (2015) A comparison of whole cell directed evolution approaches in breeding of industrial strain of Saccharomyces cerevisiae. Biotechnol Lett 37:1393–1398View ArticlePubMedGoogle Scholar
  18. Jungwoo Y, Ju YB, Young ML, Hyeji K, HyeYM Hyun AK, Su BY, Wankee K, Wonja C (2011) Construction of Saccharomyces cerevisiae strains with enhanced ethanol tolerance by mutagenesis of the TATA-Binding Protein gene and identification of novel genes associated with ethanol tolerance. Biotechnol Bioeng 108:1776–1787View ArticleGoogle Scholar
  19. Kasavi C, Eraslan S, Arga KY, Oner ET, Kirdar B (2014) A system based network approach to ethanol tolerance in Saccharomyces cerevisiae. BMC Syst Biol 8:90–104View ArticlePubMedPubMed CentralGoogle Scholar
  20. Kotarska K, Czupryński B, Kłosowski G (2006) Effect of various activators on the course of alcoholic fermentation. J Food Eng 77:965–971View ArticleGoogle Scholar
  21. Lanza AM, Alper HS (2011) Global strain engineering by mutant transcription factors. Methods Mol Biol 765:253–274View ArticlePubMedGoogle Scholar
  22. Lee TI, Young RA (1998) Regulation of gene expression by TBP-associated proteins. Genes Dev 12:1398–1408View ArticlePubMedGoogle Scholar
  23. Lee KH, Park JH, Kim TY, Kim HU, Lee SY (2007) Systems metabolic engineering of Escherichia coli for l-threonine production. Mol Syst Biol 3:149–160View ArticlePubMedPubMed CentralGoogle Scholar
  24. Lewis BA, Reinberg D (2003) The mediator coactivator complex: functional and physical roles in transcriptional regulation. J Cell Sci 116:3667–3675View ArticlePubMedGoogle Scholar
  25. Liu H, Yan M, Lai C, Xu L, Ouyang P (2010) gTME for improved xylose fermentation of Saccharomyces cerevisiae. Appl Biochem Biotechnol 160:574–582View ArticlePubMedGoogle Scholar
  26. Liu SP, Liu RX, El-Rotail AAMM, Ding ZY, Gu ZH, Zhang L, Shi GY (2014) Heterologous pathway for the production of l-phenylglycine from glucose by E. coli. J Biotechnol 186:91–97View ArticlePubMedGoogle Scholar
  27. Luhe AL, Tan L, Wu J, Zhao H (2011) Increase of ethanol tolerance of Saccharomyces cerevisiae by error-prone whole genome amplification. Biotechnol Lett 33:1007–1011View ArticlePubMedGoogle Scholar
  28. Mal TK et al (2004) Structural and functional characterization on the interaction of yeast TFIID subunit TAF1 with TATA-binding protein. J Mol Biol 339:681–693View ArticlePubMedGoogle Scholar
  29. McCullum EO, Williams BA, Zhang J, Chaput JC (2010) Random mutagenesis by error-prone PCR. In vitro mutagenesis protocols, 3rd ed. p 103–109Google Scholar
  30. Pavlov AR, Pavlova NV, Kozyavkin SA, Slesarev AI (2004) Recent developments in the optimization of thermostable DNA polymerases for efficient applications. Trends Biotechnol 22:253–260View ArticlePubMedGoogle Scholar
  31. Sinha NK, Haimes MD (1981) Molecular mechanisms of substitution mutagenesis. An experimental test of the Watson-Crick and topal-fresco models of base mispairings. J Biol Chem 256:10671–10683PubMedGoogle Scholar
  32. Tan F, Wu B, Dai L, Qin H, Shui Z, Wang J, Zhu Q, Hu G, He M (2016) Using global transcription machinery engineering (gTME) to improve ethanol tolerance of Zymomonas mobilis. Microb Cell Fact 15:1–9View ArticleGoogle Scholar
  33. Walker ME, Gardner JM, Vystavelova A, McBryde C, Lopes MD, Jiranek V (2003) Application of the reuseable, KanMX selectable marker to industrial yeast: construction and evaluation of heterothallic wine strains of Saccharomyces cerevisiae, possessing minimal foreign DNA sequences. FEMS Yeast Res 4:339–347View ArticlePubMedGoogle Scholar
  34. Wang Y, Shi WL, Liu XY, Shen Y, Bao XM, Bai FW, Qu YB (2004) Establishment of a xylose metabolic pathway in an industrial strain of Saccharomyces cerevisiae. Biotechnol Lett 26:885–890View ArticlePubMedGoogle Scholar
  35. Wang TW, Zhu H, Ma XY, Zhang T, Ma YS, Wei DZ (2006) Mutant library construction in directed molecular evolution. Mol Biotechnol 34:55–68View ArticlePubMedGoogle Scholar
  36. Xu GQ, Hua Q, Duan NJ, Liu LM, Chen J (2012) Regulation of thiamine synthesis in Saccharomyces cerevisiae for improved pyruvate production. Yeast 29:209–217View ArticlePubMedGoogle Scholar
  37. Zhang L, Tang Y, Guo ZP, Ding ZY, Shi GY (2011) Improving the ethanol yield by reducing glycerol formation using cofactor regulation in Saccharomyces cerevisiae. Biotechnol Lett 33:1375–1380View ArticlePubMedGoogle Scholar

Copyright

© The Author(s) 2017
