Roughage biodegradation by natural co-cultures of rumen fungi and methanogens from Qinghai yaks

Abstract

Anaerobic fungus–methanogen co-cultures from rumen liquids and faeces can degrade lignocellulose efficiently. In this study, 31 fungus–methanogen co-cultures were first obtained from the rumen of yaks grazing in Qinghai Province, China, using the Hungate roll-tube technique. The fungi were identified according to morphological characteristics and internal transcribed spacer (ITS) sequences. The methanogens associated with each fungus were identified by polymerase chain reaction-denaturing gradient gel electrophoresis (PCR-DGGE) and 16S rRNA gene sequencing. They were five co-culture types: Neocallimastix frontalis + Methanobrevibacter ruminantium, Neocallimastix frontalis + Methanobrevibacter gottschalkii, Orpinomyces joyonii + Methanobrevibacter ruminantium, Caecomyces communis + Methanobrevibacter ruminantium, and Caecomyces communis + Methanobrevibacter millerae. Among the 31 co-cultures, during the 5-day incubation, the N. frontalis + M. gottschalkii co-culture YakQH5 degraded 59.0%–68.1% of the dry matter (DM) and 49.5%–59.7% of the neutral detergent fiber (NDF) of wheat straw, corn stalk, rice straw, oat straw and sorghum straw to produce CH₄ (3.0–4.6 mmol/g DM) and acetate (7.3–8.6 mmol/g DM) as end-products. Ferulic acid (FA) released at 4.8 mg/g DM on corn stalk and p-coumaric acid (PCA) released at 11.7 mg/g DM on sorghum straw showed the highest values, with the following peak values of enzyme activities: xylanase at 12,910 mU/mL on wheat straw, ferulic acid esterase (FAE) at 10.5 mU/mL on corn stalk, and p-coumaric acid esterase (CAE) at 20.5 mU/mL on sorghum straw. The N. frontalis + M. gottschalkii co-culture YakQH5 from Qinghai yaks represents a new efficient combination for lignocellulose biodegradation, performing better than previously reported fungus–methanogen co-cultures from the digestive tract of ruminants.

Introduction

Abundant plant biomass is an underused feedstock for bioenergy production. Recently, anaerobic fungi have been reported to efficiently break down lignocellulosic biomass (Young et al. 2018). Studies have shown that anaerobic fungi can produce different extracellular cell–wall-degrading enzymes, including cellulases, hemicellulases, esterases, and multienzyme complexes called cellulosomes, to decompose lignocellulose materials to produce H₂, formate, acetate, ethanol and CO₂ (Gilmore et al. 2020; Mi et al. 2009, 2016). The activity of plant cell-wall-degrading enzymes secreted by the anaerobic fungi Neocallimastix patricciarum and Neocallimastix frontalis is higher than that secreted by commercial Trichoderma reesei, Aspergillus oryzae, Aspergillus nidulans and Penicillium pinophilum used in industry (Dijkerman et al. 1997; Yang and Xie 2010; Cao et al. 2013). Therefore, these fungi have wide application prospects in bioenergy, the feed industry, biogas fermentation and other related fields. Anaerobic fungi are classified in the phylum Neocallimastigomycota, which contains one class, Neocallimastigomycetes, one order, Neocallimastigales, one family, Neocallimasticaceae and 18 genera based on flagellum numbers, growth patterns and rhizoid forms (Chang and Park 2020). The whole genome sequences of Anaeromyces robustus, Neocallimastix californiae, Pecoramyces ruminantium, Piromyces finnis and Piromyces sp. E2 are available in the Joint Genome Institute Database (Chang and Park 2020).

Anaerobic fungi use different carbon sources as substrates for mixed acid fermentation, and the metabolites are mainly formate, acetate, lactate, ethanol, H₂ and CO₂ (Li et al. 2016, 2021). Methanogens can use the metabolites of anaerobic fungi, thus eliminating the feedback inhibition effect of the metabolites on growth to accelerate anaerobic fungus reproduction, promote the production of fungal ATP, and improve the activity and yield of enzymes (Wei et al. 2016). Co-cultures of an anaerobic fungus with a methanogen significantly improved their ability to degrade lignocellulosic substrates and produced a large amount of CH₄ and acetate as fermentation end-products (Jin et al. 2011), which provided a theoretical basis for applying anaerobic fungi in biogas fermentation engineering, along with high activity xylanase and acetate production.

Yak (Bos grunniens) is a rare herbivorous ruminant resource in the bovine genus that can adapt to high altitudes, cold, and anoxia (Long et al. 2008; Song et al. 2021). Yaks thrive in harsh environments and graze on wild grasses as their main source of nutrition. A large number of unique, complex, and diverse microbial communities in the yak rumen can synergistically degrade low-quality wild herbage and dry, withered cold-season grass to provide yaks with energy and nutrients, making the yak rumen a natural anaerobic fermentation system for efficiently degrading lignocellulose (Huang et al. 2021a, b; Huang et al. 2021a, b). Globally, there are more than 14 million yaks, but China is the centre of origin, with the largest numbers mainly grazing on the Qinghai–Tibetan Plateau at a 3000–6000 m elevation year round. There are approximately 4.9 million heads of yak in Qinghai Province, accounting for the largest share (38%) of the total number of yaks in China (Fan et al. 2021; Sun et al. 2011).

China is known as the yak capital of the world. The number of yaks in Qinghai Province ranks first in China. To date, no reports have been published about fungus–methanogen co-cultures from yaks grazing in Qinghai Province of China. There are a large number of different types of yaks and vegetation in the six main production areas of Qinghai Province. Different kinds of natural herbage eaten by grazing yaks lead to different microbial floras in their rumens of yaks among different areas. Therefore, there are different combinations of natural anaerobic fungus–methanogen co-cultures present in the rumen of grazing yaks in different areas. These fungus–methanogen co-cultures can efficiently degrade lignocelluloses. As there is an urgent need to effectively improve the utilization rate of many types of straws, studies focusing on the yak rumen microbiota are needed. Previous studies have reported some fungus–methanogen co-cultures from the rumen of yaks grazing in Tianzhu Tibetan Autonomous Prefecture in Gansu Province of China, with high fibrolytic enzyme activities (Wei et al. 2015, 2016, 2017). It is necessary to further systematically study fungus–methanogen co-cultures from the rumen of yaks in different areas. These microbial resources have not been fully exploited. We hypothesized that fungus–methanogen co-cultures from the rumen of yaks grazing in Qinghai Province can efficiently degrade lignocelluloses with high fibrolytic enzyme activities. This study unprecedentedly focused on isolating fungus–methanogen co-cultures from the rumen of Qinghai yaks, and further explored their capacity to degrade wheat straw, oat straw, corn stalk, rice straw and sorghum straw.

Materials and methods

Animal diet and fungus–methanogen co-cultures isolation

Plateau yak is one of the most valued yak breeds in Qinghai Province, China, and has the genes and characteristics of wild yaks. Xinghai County in Hainan Tibetan Autonomous Prefecture in Qinghai Province of China, at an altitude of 4100 m (34°48′–36°14′ N, 99°01′–100°21′ E), was chosen as the experimental site. In the spring (March), plateau yaks (n = 20, male, 4–5 years) grazing in a pasture in Xinghai County were randomly chosen to isolate single anaerobic fungi. The pasture type was alpine meadow with Festuca ovina L. as the main species. The use of animals and the procedure for rumen sample collection were approved by local farms in Hainan Tibetan Autonomous Prefecture of Qinghai Province and the Animal Ethics Committees of the Gansu Academy of Sciences (Gansu, China).

Fresh rumen liquid was collected from the rumen of each yak through a dedicated rumen content collector comprising a stainless steel stomach tube and a tiny vacuum pump. The rumen liquid samples were quickly inoculated into anaerobic tubes containing 9.0 mL basal anaerobic fungus medium and 100 mg air-dried chopped wheat straw, which were autoclaved at 121 °C for 20 min. After inoculation, 1600 IU/mL penicillin and 2000 IU/mL streptomycin were added to kill bacteria, and then the culture was placed at 39 °C. The basal anaerobic fungus medium comprised (per litre): yeast extract, 1.0 g; tryptone, 1.0 g; NaHCO₃, 7.0 g; resazurin (1.0 g/L), 1 mL; yak rumen fluid without cells centrifuged at 10,000×g for 15 min at 4 °C, 170 mL; Salt solution I, 165 mL; Salt solution II, 165 mL; l-cysteine hydrochloride, 1.7 g; and distilled water to 1000 mL. Salt solution I contained NaCl, 6.0 g/L; (NH₄)₂SO₄, 3.0 g/L; KH₂PO₄, 3.0 g/L; CaCl₂·2H₂O, 0.4 g/L and MgSO₄·2H₂O, 0.6 g/L. Salt solution II contained 4.0 g/L K₂HPO₄.

After several subcultures, the single anaerobic fungi were isolated using the Hungate roll-tube technology. Bacterial contamination in each culture was checked by PCR with the primers 968f/1401r (Su et al. 2008). The formation of CH₄ was examined using headspace gas chromatography to ensure that methanogens were present in each co-culture. By this method, we isolated single anaerobic fungi and obtained fungus–methanogen co-cultures. The cultures were transferred every 4 days to anaerobic fungus medium with 1% (w/v) wheat straw at 39 °C.

Identification of fungus–methanogen co-cultures and phylogenetic analysis

The cultures incubated for 2 to 3 days in Hungate agar tubes were observed under a light microscope. The cultures incubated in anaerobic fungus liquid medium with or without straw were observed under a phase contrast microscope (Leica, DMIL-PH1, Germany). The anaerobic fungi were first identified according to their morphological features.

The cultures incubated in 0.1% glucose (w/v) liquid medium without straw at 39 °C for 4 days were collected by centrifugation at 10,000×g at 4 °C to extract total genomic DNA. The collected pellets were finely ground using liquid nitrogen. DNA extraction was performed using the Fast DNA SPIN Kit for soil (MP Biomedical, Solon, OH, United States) according to the manufacturer’s instructions. Cell lysis in this kit was performed with sodium phosphate buffer and MT buffer in Lysing Matrix E tubes using a Precellys 24 bead beater for 40 s at a speed of 6.0 m/s.

The ITS sequence of the anaerobic fungi was amplified with the forward primer GM1 (5′-TGTACACACCGCCCGTC-3′) and reverse primer GM2 (5′-CTGCGTTCTTCATCGAT-3′) as reported by Li and Heath. The diversity of methanogens in each co-culture was analysed by the polymerase chain reaction–denaturing gradient gel electrophoresis (PCR–DGGE) method, with the primers 519f/915r GC according to Cheng et al. (2009). The 16S rDNA of methanogens was amplified to identify them using the primers Met86F (5′-GCTCAGTAACACGTGG-3′) and Met1340R (5′-CGGTGTGTGCAAGGAG-3′), and the amplification conditions of the Met primers were modified according to Wei et al. (Wei et al. 2017). All sequences of PCR products were determined by Beijing Genomics Institute (BGI) and all sequences were submitted to the GenBank database.

The amplified products were all visualized and purified by 1% agarose gel electrophoresis. The sequences obtained were aligned by using ClustalX V1.83. A Basic Local Alignment Search Tool (BLAST) search was performed with the obtained sequences to determine the homology with sequences already available in the GenBank database. The evolutionary relationships of the methanogens were plotted using the neighbour-joining method. Phylogenetic analyses and phylogenetic trees construction were conducted in MEGA 7.0.

Scanning electron microscopy

The fungus cultures grown in anaerobic medium containing 100 mg chopped straw at 1% (w/v) at 39 °C for 72 h were centrifuged at 1000×g for 5 min. The precipitate was rinsed three times with phosphate-buffered saline (PBS, pH 7.2). The samples for scanning electron microscopy (SEM) observation were prepared according to Wei et al. (2016).

Screening of co-cultures

According to a number of previous studies, the lignocellulose degradation capability of the fungus–methanogen co-cultures was positively correlated with gas production (Jin et al. 2011; Wei et al. 2015; Getachew et al. 2004; Gasmi-Boubaker et al. 2005; Sebata et al. 2011). Thus, the fungus–methanogen co-culture with wheat straw as the substrate with the highest gas production during the 5-day culture period was selected as the optimum co-culture, and its capacity for degrading five straws and their respective fermentation end-products were determined.

Experimental design and sampling

Wheat straw, oat straw, corn stalk, rice straw and sorghum straw were used as substrates, respectively. All substrates were sun-dried, chopped and ground to pass through a 2 mm screen. The inocula were the fungus–methanogen co-culture and its fungus pure culture obtained by adding chloramphenicol (50 μg/mL final concentration) to inhibit methanogens. Medium without the inoculum was used as the control. Each substrate (1 g) was added to 123 anaerobic bottles, each containing 90 mL basal medium. The 10-mL inoculum was added to basal medium sparged with highly purified CO₂ (Li et al. 2020a, b; Solomona et al. 2016; Henske et al. 2017; Ferraro et al. 2018; Hanafy et al. 2018; Joshi et al. 2018; Peng et al. 2018) and supplemented with 1600 IU/mL penicillin and 2000 IU/mL streptomycin. The cultures were incubated at 39 °C for 5 days. During the 5-day incubation, 3 bottles of the fungus–methanogen co-culture were taken out daily to determine end-products, such as CH₄ and acetate, as well as xylanase, carboxymethyl cellulase (CMCase), filter paper ase (FPase), ferulic acid esterase (FAE), acetyl esterase (AE), and p-coumaric acid esterase (CAE) activities, ferulic acid (FA), p-coumaric acid (PCA), vanillic acid (VA) and protocatechuic acid (PA) releases. And 3 bottles of the fungus pure culture were taken out daily to determine end-products. The pellets of the centrifuged cultures were collected for the analysis of in vitro dry matter digestibility (IVDMD) and neutral detergent fibre digestibility (NDFD) by the fungus–methanogen co-culture on the five straws.

Enzyme profile assays

The cultures were centrifuged at 5000×g for 10 min at 4 °C to obtain the supernatants to determine xylanase, CMCase, FPase, FAE, AE and CAE activity according to Wei (2016), Cao (2011) and the state standard of the People's Republic of China (GB/T 23874-2009). One unit of enzyme activity was defined as the amount of enzyme that released 1.0 μmol xylose, glucose, FA, p-nitrophenol, or PCA per minute per millilitre at pH6.8 and 39 °C.

Fibre digestibility determination

According to AOAC (2005) Official Methods of Analysis (18th Association of Analytical Chemists, Washington DC, USA), the samples in each bottle were centrifuged and dried at 105 °C for 24 h to determine IVDMD. NDF contents were determined as described by Van Soest et al. Alpha amylase was not used, but sodium sulfite was added to each sample for the NDF assay. The calculation was as follows: IVDMD or NDFD (%) = [(initial DM or NDF of the feed taken for incubation − DM or NDF of the residue)/(initial DM or NDF of the feed taken for incubation)] × 100. The dried residue and NDF content of the dried residue in the uninoculated control were taken as the initial DM and NDF values, respectively.

Phenolic acid release measurement

The extraction methods of FA, PCA, VA and PA from the supernatants of cultures and high-performance liquid chromatography (HPLC) analyses were performed according to the newly improved HPLC method reported by Wang et al. (2013)_.

Total gas production and CH₄ measurement

The cumulative gas production during the 5-day incubation was measured by an AGRS-III automated trace gas recording system for real-time detection of anaerobic microbial growth. CH₄ was measured by gas chromatography (GC), with an HP-Innowax (19091N-133) capillary column, high purity nitrogen as the carrier gas, and a hydrogen flame ionization detector. The determination conditions of CH₄ were established as follows: total pressure 130 kPa, total flow rate 30.2 mL/min, column flow rate 1.7 mL/min, linear velocity 39.8 cm/s, column temperature 80 °C, gasification chamber temperature 100 °C, and detection chamber temperature 120 °C.

End-product analysis

The cultures were centrifuged at 10,000×g for 10 min at 4 °C to obtain the supernatants. The formate and acetate concentrations in the supernatants were determined by HPLC (Water 2489, USA) on an instrument equipped with an Agilent SB-Aq chromatography column (26 mm × 250 mm, 5 μm, Agilent, USA), a 2489UA detector, a 7725i manual injector (Rheodyne, USA), and a UV2450 ultraviolet–visible spectrometer (Hitachi, Japan). The determination conditions were as follows: mobile phase 5 mmol/L KH₂PO₄-H₃PO₄ buffer solution (pH = 2.4), flow velocity 0.5 mL/min, detection wavelength 214 nm, column temperature 25 °C, and injection volume 20 μL. The l-lactate and d-lactate concentrations in the supernatants were analysed using an l,d-lactate Assay Kit (Nanjing Jiancheng Institute of Biological Engineering, Nanjing, China). The ethanol concentration was determined using gas chromatography according to the modified method of Boonchuay et al. (2021).

Statistical analysis

Data are shown as the mean ± standard deviation (SD) and were analysed using one-way analysis of variance (ANOVA) follwed by Tukey’s test with SPSS 18.0 software (Microsoft). p < 0.05 was considered to indicate a statistically significant difference.

Results

Isolation and identification of fungus–methanogen co-cultures from Qinghai yaks

The gas chromatography analysis showed that all isolated fungus–methanogen co-cultures produced CH₄, which confirmed the presence of methanogens in each co-culture. Bacterial specific-PCR amplification showed no detectable bacteria in any co-culture. In this study, 31 fungus–methanogen co-cultures were obtained from the rumen of plateau yaks grazing in Hainan Tibetan Autonomous Prefecture in Qinghai Province, China (Table 1). Among the 31 co-cultures, there were 5 types: N. frontalis + M. ruminantium, N. frontalis + M. gottschalkii, O. joyonii + M. ruminantium, C. communis + M. ruminantium, and C. communis + M. millerae. They were identified and named N. frontalis + M. ruminantium co-culture YakQH1-YakQH4, N. frontalis + M. gottschalkii co-culture YakQH5-YakQH16, O. joyonii + M. ruminantium co-culture YakQH17-YakQH23, C. communis + M. ruminantium co-culture YakQH24-YakQH26, and C. communis + M. millerae co-culture YakQH27-YakQH31. Each anaerobic fungal strain was symbiotic with a methanogen species. The fungal isolates were named N. frontalis YakQH1-YakQH16, O. joyonii YakQH17-YakQH23, and C. communis YakQH24-YakQH31, and the methanogen isolates were named M. ruminantium YakQH1-YakQH4, M. gottschalkii YakQH5-YakQH16, M. ruminantium YakQH17-YakQH23, M. ruminantium YakQH24-YakQH26, and M. millerae YakQH27-YakQH31 (Table 1).

Table 1 Classification of the 31 fungus–methanogen co-cultures isolated from the rumen of Qinghai yaks

The 31 fungi in the co-cultures were observed and identified using light microscopy, phase contrast microscopy, and SEM according to morphological characteristics and the number of zoospore flagella (Figs. 1, 2, 3). The fungal isolates N. frontalis YakQH1-YakQH16, O. joyonii YakQH17-YakQH23, and C. communis YakQH24-YakQH31 showed the morphological features of N. frontalis, O. joyonii, and C. communis, respectively. The ITS sequences of the 31 fungi in the co-cultures were deposited in GenBank under accession numbers MH482796-MH482826 (Table 1). Through sequence homology comparison with the NCBI database, among the 31 co-cultures, all fungal isolates had a similarity of 99%–100% with N. frontalis strain Yak16, O. joyonii strain Yak1, and Caecomyces sp. AGRL-11 registered in GenBank.

Fig. 1

Morphological diversity of anaerobic fungi isolates in Hungate agar roll-tubes. A The fungus N. frontalis YakQH5 with an endogenous sporangium and a network of rhizoids. B The fungus O. joyonii YakQH17 produced a rhizomycellium complex with an extensive network of hyphae, single or branched sporangiophores developed from the hyphae, and several globose sporangia full of zoospores were produced from the sporangiophores. C The fungus C. communis YakQH24 colony. Bars = 100 μm

Fig. 2

Growth stages of the fungus C. communis YakQH24 in liquid glucose culture medium under phase -contrast microscopy. A A live uniflagellate zoospore. Bars = 10 μm. B The fungus C. communis YakQH24 showed bulbous rhizoids after 24 h incubation. Bars = 10 μm. C The C. communis YakQH24 produced more bulbous rhizoids after 96 h incubation. Bars = 50 μm

Fig. 3

SEM of the anaerobic fungus N. frontalis YakQH5. A The mycelium of the N. frontalis YakQH5 penetrated into the thick-walled tissue of wheat straw after 24 h incubation. B The N. frontalis YakQH5 grew with an endogenous sporangium growth after 48 h incubation. C The dense hyphae of the N. frontalis YakQH5 fully penetrated into the wheat straw tissue to physically degrade lignocellulose after 96 h incubation. Bars = 20 μm

The DGGE results confirmed that one fungus was natively associated with only one methanogen in each co-culture. The 16S rRNA gene sequences of the 31 methanogens in the co-cultures were deposited in GenBank under accession numbers MH443285-MH443315 (Table 1). All methanogen isolates (YakQH1-YakQH31) in the 31 co-cultures belonged to Methanobrevibacter sp. based on the 16S rRNA gene sequences. Through sequence homology comparison with the NCBI database, among the 31 co-cultures, all methanogen isolates were found to have a similarity of 99%-100% with M. ruminantium strain YakM2, M. gottschalkii strain PG, and M. millerae strain ZA-10 registered in GenBank.

Phylogenetic tree construction of methanogens

A phylogenetic tree of the 16S rRNA gene sequences of methanogen isolates YakQH1-YakQH31 was constructed. Methanomicrobium mobile BP was used as an outgroup. The results showed that the 31 strains of methanogens included 3 species: M. ruminantium, M. gottschalkii, and M. millerae (Fig. 4).

Fig. 4

Phylogenetic tree of the 16S rRNA gene sequences of the methanogens isolates YakQH1–YakQH31 in the fungus–methanogen co-cultures. The topology of the tree was estimated by bootstraps based on 1000 replications. Bootstrap values more than 70% were shown on the major branch points. The scale bar corresponds to five changes per 100 positions. The 16S rRNA sequences determined in the present study and the closest relatives were marked in bold type. Methanomicrobium mobile BP (NR_044726) was used as an out group. GenBank accession numbers were given in brackets

Screening of co-cultures

Among the 31 fungus–methanogen co-cultures, the 12 co-cultures of N. frontalis + M. gottschalkii grew most stably and rapidly and degraded wheat straw in anaerobic tubes to produce the highest total gas yields of 181–230 mL/g DM during the 5-day incubation, obviously more than other co-cultures. Particularly, the N. frontalis + M. gottschalkii co-culture YakQH5 was the most remarkable and was thus selected to determine its ability to biodegrade five types of roughage as substrates. The preservation number of the N. frontalis + M. gottschalkii co-culture YakQH5 was No. 19299 in the China General Microbiological Culture Collection Center (CGMCC).

Enzyme profiles

During the 5-day incubation, in anaerobic bottles, the N. frontalis + M. gottschalkii co-culture YakQH5 degraded wheat straw, corn stalk, rice straw, oat straw and sorghum straw and showed the highest activity values of 12,910 mU/mL xylanase on wheat straw, 929 mU/mL CMCase and 1187 mU/mL FPase on rice straw, 10.5 mU/mL FAE and 245 mU/mL AE on corn stalk, and 20.5 mU/mL CAE on sorghum straw (Table 2).

Table 2 Fibrolytic enzyme of the N. frontalis + M. gottschalkii co-culture YakQH5 grown on the 5 sorts of substrates

Fibre digestibility

During the 5-day incubation, in anaerobic bottles, the N. frontalis + M. gottschalkii co-culture YakQH5 degraded 60.5% of wheat straw, 67.2% of corn stalk, 68.1% of rice straw, 59.0% of oat straw, and 63.1% of sorghum straw (Fig. 5). Additionally, the co-culture YakQH5 had NDFD values of 49.5% on wheat straw, 59.7% on corn stalk, 55.8% on rice straw, 51.0% on oat straw, and 53.1% on sorghum straw (Fig. 5). The composition of the forages used as substrates before incubation was shown in Table 3.

Fig. 5

Fiber digestibility of the N. frontalis + M. gottschalkii co-culture YakQH5 grown on the 5 sorts of substrates. Left: In vitro dry matter digestibility (IVDMD); Right: Neural detergent fiber digestibility (NDFD). ws: wheat straw; cs: corn stalk; rs: rice straw; os: oat straw; ss: sorghum straw

Table 3 Composition of the forages used as substrates before incubation

Phenolic acid release

During the 5-day incubation, in anaerobic bottles, the N. frontalis + M. gottschalkii co-culture YakQH5 degraded wheat straw, corn stalk, rice straw, oat straw, and sorghum straw to release FA 3.4–4.8 mg/g DM, PCA 3.4–11.7 mg/g DM, VA 0.4–0.7 mg/g DM and PA 0.5–0.9 mg/g DM, respectively. The peak values were as follows: FA 4.8 mg/g DM on corn stalk, PCA 11.7 mg/g DM on sorghum straw, VA 0.7 mg/g DM on rice straw, and PA 0.9 mg/g DM on wheat straw (Fig. 6).

Fig. 6

Releases of phenolic acids by the N. frontalis + M. gottschalkii co-culture YakQH5 grown on the 5 sorts of substrates. ● cs: corn stalk; ■ ws: wheat straw; ▲ rs: rice straw; ▼ os: oat straw; * ss: sorghum straw

Fermentation end-products

During the 5-day incubation, in anaerobic bottles, the N. frontalis + M. gottschalkii co-culture YakQH5 degraded wheat straw, corn stalk, rice straw, oat straw and sorghum straw to produce high total gas yields (the gas was mainly composed of CH₄) of 315 mL/g DM, 261 mL/g DM, 300 mL/g DM, 290 mL/g DM, and 284 mL/g DM, respectively (Fig. 7). Meanwhile, the N. frontalis + M. gottschalkii co-culture YakQH5 degraded these lignocellulosic materials to produce the highest end-product yields as follows: CH₄ 4.6 mmol/g DM on wheat straw and acetate 8.6 mmol/g DM on rice straw (Table 4). The fungus N. frontalis YakQH5 degraded these lignocellulosic materials to produce maxima of H₂ 3.9 mmol/g DM on wheat straw, formate 2.5 mmol/g DM on sorghum straw, acetate 5.5 mmol/g DM on rice straw, lactate 2.5 mmol/g DM on sorghum straw, and ethanol 45.8 mmol/g DM on wheat straw (Table 4).

Fig. 7

Gas production by the N. frontalis + M. gottschalkii co-culture YakQH5 grown on the 5 sorts of substrates. ● cs: corn stalk; ■ ws: wheat straw; ▲ rs: rice straw; ▼ os: oat straw; * ss: sorghum straw

Table 4 End-products produced by the N. frontalis + M. gottschalkii co-culture YakQH5 and the N. frontalis YakQH5 fungus grown on the 5 substrates

Discussion

Diversity of the fungus–methanogen co-cultures from the rumen of grazing yaks

In this study, 31 natural fungus–methanogen co-cultures were first obtained from the rumen fluid of grazing yaks in spring in Qinghai Province, China, comprising 5 combination types: N. frontalis + M. ruminantium, N. frontalis + M. gottschalkii, O. joyonii + M. ruminantium, C. communis + M. ruminantium, and C. communis + M. millerae. In 2015, we isolated 20 natural fungus–methanogen co-cultures from the rumen fluid of grazing yaks in spring in a Wushaoling pasture of Tianzhu Tibetan Autonomous Prefecture in Gansu Province, China, including 4 combination types: N. frontalis + M. ruminantium, O. joyonii + M. ruminantium, O. joyonii + M. millerae, and Piromyces + M. ruminantium (Wei et al. 2015, 2016). Thus, there were many types of natural fungus–methanogen co-cultures in the rumen of grazing yaks. Furthermore, when compared to the reported natural fungus-methanogen co-cultures isolated from the rumen or faeces of ruminants and non-ruminants by Bauchop et al. (1981), Jin et al. (2011), Leis et al. (2014), Sun et al. (2014), Li et al. (2016) and Li et al. (2021) and grazing yaks by Wei et al. (2015, 2017), in this study, 3 new types of natural anaerobic fungus–methanogen co-culture combinations were first obtained from the rumen of yaks, namely: N. frontalis + M. gottschalkii, C. communis + M. ruminantium, and C. communis + M. millerae. These three types of fungus-methanogen co-cultures all included one fungus and one methanogen, and each methanogen coexisting with each fungus belonged to Methanobrevibacter sp., consistent with the natural fungus–methanogen co-cultures isolated from the rumen or faeces of ruminants and non-ruminants previously reported by Jin et al. (2011), Leis et al. (2014), Sun et al. (2014), Li et al. (2016), Li et al. (2021) and Wei et al. (2015, 2017).

Our study revealed that different combinations of natural fungus–methanogen co-cultures in the rumen of grazing yaks in different regions, probably because of the different types of wild herbages eaten by the grazing yaks in different areas, and these different types of natural fungus–methanogen co-cultures differed in their ability to degrade lignocelluloses. This suggests that there are new and abundant microbial resources for efficiently degrading lignocelluloses in the rumen of yaks grazing on the Qinghai-Tibet Plateau, which have not yet been fully explored.

Roughage degradation by fungus–methanogen co-cultures from the rumen of grazing yaks

During the 5-day incubation, the N. frontalis + M. gottschalkii co-culture YakQH5 degraded the 5 kinds of roughages and showed degradation potential, including high lignocellulose-degrading enzyme activities, IVDMD 59.0%-68.1% (from oat straw to rice straw), NDFD 49.5%-59.7% (from wheat straw to corn stalk) and large amounts of FA and PCA releases, which are described in Sect. 3. Accordingly, we found that the degradation degrees of roughages were different. Ranked in terms of highest to lowest decomposition, the substrates were rice straw, corn stalk, sorghum straw, wheat straw, and oat straw, while in terms of highest to lowest degradation, they were corn stalk, rice straw, sorghum straw, oat straw, and wheat straw. The N. frontalis + M. gottschalkii co-culture YakQH5 degraded lignocelluloses by secreting main-chain degrading polysaccharide hydrolases (CMCase, FPase and xylanase) and side-chain degrading esterases (FAE, AE and CAE) with high activities, which could be key lignin-degrading enzymes in enhancing plant cell wall degradation. All these enzymes acted synergistically to effectively decompose lignocelluloses. The N. frontalis + M. gottschalkii YakQH5 degraded sorghum straw to release PCA 11.7 mg/g DM (70.1 μg/mL) as a result of the high PCA content in sorghum straw, consistent with the high activity of CAE when using sorghum stalk as a substrate, implying that the N. frontalis + M. gottschalkii YakQH5 from the rumen of Qinghai yaks can decompose lignin efficiently. Meanwhile, the N. frontalis + M. gottschalkii co-culture YakQH5 degraded wheat straw, corn stalk, rice straw, oat straw and sorghum straw to release very small amounts of VA and PA. The yields of VA and PA releases appeared unrelated to their contents in the roughages. Further study is needed to clarify this finding.

Among the 31 fungus–methanogen co-cultures, the N. frontalis + M. gottschalkii co-culture YakQH5 was screened out with only wheat straw as substrate by measuring gas production. In this case, the lignocellulose degradation and gas production are generally positive correlation.

The N. frontalis + M. gottschalkii co-culture YakQH5 degraded different roughages as substrates, the order of the lowest to highest IVDMD was: oat straw, wheat straw, sorghum straw, corn stalk, and rice straw; the order of the lowest to highest NDFD was: wheat straw, oat straw, sorghum straw, rice straw and corn stalk; and the order of the lowest to highest gas production was: corn stalk, sorghum straw, oat straw, rice straw and wheat straw. When the 5 kinds of roughages with different lignocellulose contents were used as substrates, there was not always a linear correlation between IVDMD, NDFD and gas production. This phenomenon may have been related to the different compositions of the five roughages. The lignocellulose degradation mechanism of the anaerobic fungi needs to be further studied to reveal the reason behind this phenomenon.

In 2015 and 2017, we first reported the natural fungus–methanogen co-culture N. frontalis + M. ruminantium Yaktz1 and Piromyces + M. ruminantium Yak-G18 that degraded straws with remarkable efficiency were isolated from the rumen of yaks grazing in Tianzhu Tibetan Autonomous County in Gansu Province of China (Wei et al. 2015, 2016, 2017). During the 7-day incubation, the N. frontalis + M. ruminantium co-culture Yaktz1 degraded 61.7% of wheat straw, 68.8% of corn stalk, and 71.9% of rice straw, with NDFD values of 56.0% on wheat straw, 61.7% on corn stalk, and 55.6% on rice straw, while exhibiting the highest enzyme activity values as follows: xylanase 12,500 mU/mL on wheat straw; FPase 430.3 mU/mL, FAE 11.4 mU/mL, AE 199.3 mU/mL and CAE 5.0 mU/mL on corn stalk, and FA release 24.1 μg/mL and PCA release 50.3 μg/mL on corn stalk as the peak values. Across the 7-day incubation, the Piromyces + M. ruminantium co-culture Yak-G18 degraded 60.5% of wheat straw, 65.0% of corn stalk, 65.9% of rice straw, 66.0% of Chinese wildrye, and 75.0% of alfalfa, with NDFD values of 40.8%–47.5% on the five substrates, showing peak values of xylanase activity ranging from 2750 to 5023 mU/mL (from alfalfa to Chinese wildrye), FPase ranging from 71.9 to 123.5 mU/mL(from rice straw to Chinese wildrye), and AE 66.3–118.1 mU/mL (from alfalfa to Chinese wildrye), releasing little FA and PCA. To date, 3 types of extremely effective fungus–methanogen co-cultures for straw degradation have been obtained from the rumen of yaks: the N. frontalis + M. ruminantium co-culture Yaktz1, the Piromyces + M. ruminantium co-culture Yak-G18, and the N. frontalis + M. gottschalkii co-culture YakQH5. According to degradation capability, the N. frontalis + M. ruminantium co-culture Yaktz1 and N. frontalis + M. gottschalkii co-culture YakQH5 showed the most prominent ability to degrade straws. The N. frontalis + M. gottschalkii co-culture YakQH5 from Qinghai yaks decomposed wheat straw, corn stalk, rice straw, oat straw, and sorghum straw to produce higher xylanase, FPase, and CAE activities than the N. frontalis + M. ruminantium co-culture Yaktz1 from Tianzhu yaks, other natural fungus-methanogen co-cultures (from rumen or faeces of ruminants and non-ruminants), and artificially mixed anaerobic fungus–methanogen co-cultures previously reported, with all kinds of roughages or fiter paper as substrates (Jin et al. 2011; Teunissen et al. 1992a, b; Wei et al. 2015, 2016, 2017). Specifically, the N. frontalis + M. gottschalkii co-culture YakQH5 showed FPase activity on corn stalk that was approximately 2.7 times higher than that of the N. frontalis + M. ruminantium co-culture Yaktz1 on corn stalk. The xylanase produced by N. frontalis + M. gottschalkii YakQH5 has good prospects for industrial application. Concurrently, the N. frontalis + M. gottschalkii co-culture YakQH5 could effectively degrade wheat straw, corn stalk and rice straw with IVDMD and NDFD values analogous to those of the N. frontalis + M. ruminantium co-culture Yaktz1 (Wei et al. 2016) but obviously higher IVDMD values than for other fungus–methanogen co-cultures from the rumen or faeces of ruminants and non-ruminants previously reported, with roughages as substrates (Jin et al. 2011). Values of 33.6%–53.1% IVDMD for wheat straw, corn stalk, bagasse, distiller’s dried grains with solubles (DDGS), wheat bran and rice straw by the Piromyces + M. thaueri CW co-culture from the rumen of goats; 26.8%–57.0% IVDMD for wheat straw, corn stalk, bagasse, DDGS, wheat bran, and rice straw by the Piromyces + Methanobrevibacter sp. Z8 co-culture from the rumen of goats; and 33.5%–48.3% IVDMD for rice straw by the Anaeromyces + M. gottschalkii strain PG co-culture from faeces of mules, the Piromyces + M. gottschalkii strain PG co-culture from faeces of mules, the Piromyces + Methanobrevibacter sp. Z8 co-culture from faeces of camel, the Neocallimastix + Methanobrevibacter sp. Z8 co-culture from feces of camel, and the Piromyces + Methanobrevibacter sp. 1Y co-culture from feces of buffalo, all after a 5-day incubation. The N. frontalis + M. ruminantium co-culture Yaktz1 degraded wheat straw, corn stalk, and rice straw to release the maximum values of FA 24.1 μg/mL and PCA 50.3 μg/mL on corn stalk, slightly lower than those of the N. frontalis + M. gottschalkii co-culture YakQH5 with corn stalk as substrate (Wei et al. 2016).

Our study showed that the N. frontalis + M. gottschalkii co-culture YakQH5 and the N. frontalis + M. ruminantium co-culture Yaktz1 from the rumen of grazing yaks degraded roughages more effectively than previously reported fungus-methanogen co-cultures from the digestive tract of herbivores, including ruminants and non-ruminants, and even some current industrial strains. This study also highlighted that a new-type fungus–methanogen combination, the N. frontalis + M. gottschalkii YakQH5, has been obtained from the rumen of Qinghai yaks, and it can superiorly degrade lignocellulosic materials. The N. frontalis + M. ruminantium co-culture Yaktz1 was isolated from yaks grazing in a Wushaoling pasture located in Tianzhu Tibetan Autonomous Prefecture in Gansu Province of China, an alpine meadow pasture with Kobresia myosuroides (Villars) Foiri as the main species, while the N. frontalis + M. gottschalkii co-culture YakQH5 was isolated from yaks grazing in Xinghai County located in Hainan Tibetan Autonomous Prefecture in Qinghai Province of China, where the pasture was alpine meadow with Festuca Ovina L. as the main species. It can be concluded that the combinations of fungus–methanogen co-cultures from the grazing yaks in different regions may vary, and these natural fungus–methanogen co-cultures had different characteristics and abilities to degrade lignocelluloses. Further studies on the host specificity or substrate specificity of anaerobic fungi are needed.

Meanwhile, the N. frontalis + M. gottschalkii co-culture YakQH5 degraded wheat straw straw, corn stalk, rice straw, oat straw, and sorghum straw to produce the highest yields of CH₄ 4.6 mmol/g DM on wheat straw and acetate 8.6 mmol/g DM (55.7 mM) on rice straw. These are slightly higher yields than the CH₄ and acetate yields produced by the N. frontalis + M. ruminantium co-culture Yaktz1 with wheat straw, corn stalk, and rice straw as substrates during the 7-day incubation; markedly higher than those produced by the Piromyces + M. ruminantium co-culture Yak-G18 on wheat straw, corn stalk, rice straw, Chinese wildrye, and alfalfa during the 7-day incubation; and higher than those produced by most of natural fungus–methanogen co-cultures from the rumen or faeces of ruminants and non-ruminants, and artificially mixed anaerobic fungus–methanogen co-cultures, with roughages, fiter paper, cellulose or glucose as substrates (Jin et al. 2011; Teunissen et al. 1992a, b; Li et al. 2016; Nakashimada et al. 2000; Wei et al. 2015, 2016, 2017).

After methanogen inhibition, the pure fungus N. frontalis YakQH5 degraded wheat straw, corn stalk, rice straw, oat straw and sorghum straw to produce the highest yields of H₂ 3.9 mmol/g DM and ethanol 45.8 mmol/g DM (260.1 mM) on wheat straw, formate 2.5 mmol/g DM (15.0 mM) on sorghum straw, and lactate 2.5 mmol/g DM (15.0 mM) on sorghum straw. The yields of these end-products were generally higher than those produced by anaerobic fungi from the digestive tract of common ruminants and non-ruminants. The most interesting finding was that its ethanol yield was more greater than that produced by all reported anaerobic fungi with many kinds of roughages as substrates, even exceeding those of some industrial strains that produced ethanol (Jin et al. 2011; Sirohi et al 2013; Nagpal et al. 2011; Paul et al. 2010; Teunissen et al. 1992a, b; Sijtsma and Tan 1993; Thareja et al. 2006; Wei et al. 2016, 2017; Saye et al. 2021). Thus, the fungus N. frontalis YakQH5 is promising for use in the development of ethanol production.

Prospects for the fungus–methanogen co-cultures from the rumen of grazing yaks

Anaerobic fungi have been studied for more than 40 years and are considered to play a crucial role in degrading lignocelluloses. Some methanogens can further enhance the anaerobic fungi's ability to degrade lignocelluloses. Anaerobic fungus–methanogen co-cultures degrade lignocellulosic materials to produce CH₄, acetate and lignocellulose degradation enzymes with high activities, even exceeding those of some industrial strains (Teunissen et al. 1993; Cheng et al. 2018; Mountfort and Asher 1989; Solomon et al. 2016; Yang and Xie 2010; Chang and Park 2020). However, until now, anaerobic fungi have not been used for widespread industrial applications due to their strict anaerobic growth requirements, limited preservation methods, difficulty in scale-up, and genetic intractability. Recently, with the improvement of culture media, more species of anaerobic fungi have been discovered and a large number of their nucleotides and proteins have been sequenced (Chang et al. 2020; Hess et al. 2020).

In the present study, the 31 fungus–methanogen co-cultures were first obtained from the rumen of yaks grazing in Qinghai Province of China. These co-cultures included 5 combination types. Among them, during the 5-day incubation, the new-type combination N. frontalis + M. gottschalkii co-culture YakQH5 degraded 59.0%–68.1% of the DM and 49.5%–59.7% of the NDF of wheat straw, corn stalk, rice straw, oat straw and sorghum straw to produce CH₄ (3.0–4.6 mmol/g DM) and acetate (7.3–8.6 mmol/g DM) as end-products and released the most FA (4.8 mg/g DM) on corn stalk, PCA (11.7 mg/g DM) on sorghum straw. The peak values of enzyme activitie were as follows: xylanase 12,910 mU/mL on wheat straw, FAE 10.5 mU/mL on corn stalk and CAE 20.5 mU/mL on sorghum straw. The N. frontalis + M. gottschalkii co-culture YakQH5 degraded roughages to produce higher xylanase, CMCase, FAE, AE activities, IVDMD, NDFD, and more CH₄ and acetate yields without any pretreatment, than reported for natural fungus–methanogen co-cultures isolated from the digestive tract of ruminants and non-ruminants. This study convincingly proved our original hypothesis that Yak-derived ruminal fungus–methanogen co-cultures have evolved to possess high efficiency to degrade plant lignocellulose.

In follow-up studies, it will be useful strategy to further construct a large-scale continuous culture facility to produce natural complex lignocellulose-degrading enzymes, CH₄ and acetate by the N. frontalis + M. gottschalkii co-culture YakQH5, or express its xylanase, CMCase, FEA, AE and CAE genes under aerobic conditions using molecular biology techniques to realize large-scale industrial production and application. The study on combined multiple omics analysis including genomics, transcriptomics, proteomics and metabolomics of the N. frontalis + M. gottschalkii co-culture YakQH5 will help to reveal its lignocellulose degradation mechanism. The fermentation process of the fungus–methanogen co-cultures is mainly carried out in the cytoplasm and hydrogenosomes, and the detailed fermentation mechanism also needs to be further studied and optimized. The fungus–methanogen co-cultures can efficiently degrade and change lignocelluloses into CH₄ and acetate, representing potential for biological energy production that cannot be ignored. Therefore, screening the dominant combination of fungus–methanogen co-cultures from grazing yaks for the production of high-quality cellulase, hemicellulase, esterase and CH₄ will have broad application prospects. Improving the preservation methods of anaerobic fungi with high activity will further promote their practical application in industrial and agricultural production. In the future, the study of the fungus–methanogen co-cultures from the rumen of Qinghai yaks will potentially be highly important to address feed shortages, agricultural wastes utilization, environmental pollution and energy crises.
