- Original article
- Open Access
- Published:
A novel coconut-malt extract medium increases growth rate of morels in pure culture
AMB Express volume 11, Article number: 167 (2021)
Abstract
Morels are gourmet wild edible mushrooms that can grow on several substrates with significant growth rate variations. Such variations have hindered the development of a standardized culture media to promote morel’s sustainable production. The aim of this study is developing a novel culture media that takes advantage of coconut water as a complementary component of culture media. Coconut water has been extensively used as a growth-promoting component for plant tissue cultures; however, its application as component of fungi cultivation medium has not been fully developed. This study confirms that coconut water can be efficiently used as culture media component for morels using a kinetic characterization. Morchella sp. kinetic growth is evaluated in different cultures: agar, malt extract agar (MEA), lactose, coconut water (15%) and combinations of them. Kinetic growth parameters (lag phase, λ and maximum specific growth rate, µmax) are estimated using primary modeling methods. Among the selected models, the best fit is achieved using Baranyi’s model. A significant increase from 15.8% to 43.4% of the µmax values was observed when culture media (agar, lactose, MEA) is supplemented with coconut water. The largest values of µmax are obtained in MEA-coconut cultures (21.13 ± 0.43–22.57 ± 0.35). Micro-sclerotia and late sclerotia are observed in all cultures containing coconut water justifying the development of a feasible and cost-effective way of culturing morels. The results demonstrate that coconut water can be used for formulation of standard media for morel cultivation leading to a cheap alternative to produce dense mycelium and promote sclerotia formation.
Key points
Coconut water can be used for the formulation of a standard culture media for morels.
Non-linear models are a robust parametric strategy to describe morels growth.
Morel high quality mycelium and sclerotia can be produced by using coconut water.
Introduction
Morels are edible mushrooms which are highly appreciated worldwide due to their diverse usages in both food and pharmaceutical industries. All species of this genus are edible. Morels are widely distributed in temperate and subtropical forest because they can grow at different temperatures and altitudes (El-Gharabawy et al. 2019; Liu et al. 2017; Loizides 2017; Pilz et al. 2007; Goldway et al. 2000; Guzmán and Tapia 1998). In Mexico, morel fruiting time is from August to October. Due to its culinary and medicinal importance, wild morels are intensively collected implying the overexploitation risk of wild populations (Raut et al. 2019). Moreover, their profitable commerce at local and international markets justifies the necessity of developing artificial cultivation process (Raut et al. 2019; Liu et al. 2017; Du et al. 2015; Pilz et al. 2007).
Commercial artificial cultivation under controlled environmental conditions has not been achieved yet. Nevertheless, outdoors cultivation (including the entailed limitations) is a common practice in China (Liu et al. 2017; Du et al. 2015). The potential drawbacks in outdoor cultivation include low mycelium and sclerotia productivities. One of the main reasons of this significant problem is a consequence of the large variations in growth rates during the first phase of morel cultivation (Guler and Ozkaya 2008). The variations of growing capabilities are associated to fungal species, isolates and culture media (Guler and Ozkaya 2008; Winder 2006; Hervey et al. 1978). Despite morel mycelium grows on a wide variety of substrates (Brock 1951), there is no consensus regarding a standard culture broth formulation for morel in vitro mycelial growth.
Since the presence of sclerotia is an essential condition for the fruiting bodies formation, their production is a relevant step during morel cultivation (Liu et al. 2018; Kanwal and Reddy 2012; Guler and Ozkaya 2008; Winder 2006; Amir et al. 1992, 1993, 1995; Buscot 1993; Volk and Leonard 1989; Ower et al. 1986; Ower 1982). Sclerotia are defined as resistance structures against hostile environmental conditions (Pilz et al. 2007; Georgiou et al. 2006). Usually, they appear in Ascomycetes and Basidiomycetes (Georgiou et al. 2006). True sclerotia are nodules of differentiated mycelium, but in morels these structures are pseudosclerotia or false sclerotia because the mycelium is only a mass of undifferentiated hyphae (Pilz et al. 2007; Volk and Leonard 1990). Although the most appropriate term would be “pseudosclerotia”, the term “sclerotia” on morels was adopted for simplicity (Pilz et al. 2007). Due to the importance of sclerotia, nearly all studies have been focused on promoting sclerotia formation (Liu et al. 2018; Kanwal and Reddy 2012; Guler and Ozkaya 2008; Winder 2006; Amir et al. 1992, 1993, 1995; Buscot 1993) leaving aside the production of good quality mycelium and description of mycelial growth. Furthermore, development of a standard culture media for morel has not been properly tackled.
Numerous culture media have been tested with the aim of promoting large amounts of sclerotia. Several variations on carbon and nitrogen sources were tested, but sclerotia production was neither constant nor related enough to the carbon/nitrogen ratio (Kanwal and Reddy 2012; Guler and Ozkaya 2008; Buscot 1993). When a considerable amount of sclerotia was produced, the culture media were either very expensive or difficult to formulate. Thus, formulation of cost-effective culture media for high scale cultivation process has not been achieved yet.
Among the supplementary compounds added to culture media, coconut water has been extensively used as a growth-promoting component for plant tissue cultivation (Winarto and da Silva 2015; Prando et al. 2014; Peixe et al. 2007). Despite coconut water increased growth rate of few species of Basidiomycetes (Zurbano et al. 2017; Jacob et al. 2015; Magday et al. 2014) and increased biomass production of Ascomycete Ophiocordyceps sinensis (Shashidhar et al. 2017), its use as a culture supplement for mushroom cultivation has not been fully developed.
In this study:
-
it is demonstrated that utilization of coconut water as a supplement culture media enhances growth rate of morel mycelium.
-
sclerotia production can be achieved by supplementing the culture media with coconut water.
-
morel mycelium growth by using primary modeling is described for the first time.
Methods
Fungal isolates
Morel mycelia were isolated from six wild ascomata collected during September- October 2018 and August 2019 at locations listed in Table 1. Two ascomata of Morchella sp. were bought on September 2018 at the local market Melchor Múzquiz in Mexico City. According to the information provided by the seller, the ascomata came from Río Frio, Puebla. Ascomata from San Pedro Tlalcuapan were donated at the Vth Festival for the Culture of Wild Mushrooms, held from August 29 to September 1, 2019. Description data of ascomata, strains and molecular data are in process of publication.
Morchella crassipes CDBB-H-482 reference strain (World Data Centre for Microorganisms of World Federation for Culture Collections) also referred as Morchella esculenta, was acquired at the National Collection of Microbial Cell Strains of the Advanced Studies Research Center of the Instituto Politécnico Nacional and incorporated to all the experiments for comparison purposes. In the present study CDBB-H-482 strain was referred as M. esculenta instead of M. crassipes.
Isolating procedures
Collected ascomata were dried and stored at 4 °C until analysis. Ascospores of each dried ascoma were obtained by cutting a slice of the ridge under standard conditions. Dry tissue was transferred into a sterilized tube containing an antibiotic solution (neomycin, 1.75 mg mL−1; polymyxin B, 5000 UI; bacitracin, 0.025 mg mL−1) and incubated for 30 min. The tissue was transferred into another tube containing sterile distilled water. The tissue was shacked up several times and a set of dilutions were prepared to obtain 100–300 ascospores per 1000 µL of sterile distilled water. An aliquot of 100 µL of the ascospore suspension and an aliquot of 100 µL of the antibiotic solution were placed in Petri dishes. The culture media contained 12 gL−1 of bacteriological agar and coconut water (15%). After four of five days, each culture was sub-cultured on malt extract agar (MEA) and stored for growth tests. Coconut water-agar media (containing 12 gL−1, 15%) was chosen because attempts to germinate ascospores in potato dextrose agar (PDA) and MEA were most of times unsuccessful. In all the experiments, coconut water was obtained from immature nuts of approximately six months old (Prades et al. 2012) containing very few flesh and large amounts of water.
Experimental design
To assess growth rate, the experiment was divided into two stages. At the first stage, seven different culture media were tested using one wild strain (isolate FRE-3C) and the reference strain (M. esculenta, CDBB-H-482). For the second stage, the optimal culture medium was chosen to grow all wild morel isolates: FRE-5E, FRE-6F, FRE-I, FRE-L and FRE-M. Ten replicates were performed per treatment.
Culture media
The fundamental culture media were prepared using agar medium (20 gL−1), agar-coconut water, hereafter referred to as “coconut” (20 gL−1, 15%), agar malt extract (20 gL−1, 20 gL−1) and agar-lactose (20 gL−1, 0.037 M). Lactose was incorporated to the culture broths due to it is considered a low-cost but efficient carbon source for morel cultures (Winder 2006).
Combinations of agar-lactose-conut, MEA-coconut and agar-MEA-lactose were also prepared. All culture media were autoclaved at 121 °C (15 psi) for 20 min. A volume of 15 mL of sterile medium was poured into Petri dishes (90 × 15 mm) and incubated at 28 °C for 48 h for sterility test. Mycelium circular inocula (~ 0.8 cm diameter) of morel strains were transferred from a fresh MEA growing culture to Petri dishes containing the different culture broths. All the cultures were incubated at 20–25 °C in darkness. Growth was calculated by measuring the radial growth of the mycelium every day for a period of 3 to 6 days using a non-linear parameterized modeling strategy based on different fungal growth models.
Morel mycelial growth kinetics
With the aim of having a better understanding of morel mycelium growth, all the experiments carried out were fitted by using primary modeling. Linear, Baranyi’s and modified Logistic models (Table 2) were tested in order to use the traditional models of fungal growth. The selection of these three models allows description of growth curves with different levels of accuracy of the corresponding kinetic parameters (Marín et al. 2008; Baty and Delignette-Muller 2004; Zwietering et al. 1990). The inner comparison of such kinetic parameters obtained for each model yields to characterize the effect of introducing coconut water as an additional component of the culture broth for morels.
In the models included in Table 2, \(\mu_{max}\) = maximum growth rate (mm d−1), \(y_{max}\) = maximum diameter attained, \(y_{0}\) = initial diameter or inoculum diameter, \(t\) = time, \(\lambda\) = lag phase before visible growth (d), e = 2.7183 and \(A\) = is the upper asymptotic value.
Modeling strategy
Considering that the selected models are defined with nonlinear parameters (including the linear form), an online adaptive parametric estimation method was proposed based on the Levenberg–Marquardt method.
The method used the following procedure:
-
1.
Collect data \(y\left( {kT} \right)\) with \(k\) defining the sampled radius of the morel growth in the Petri dish, and \(T\) the sampling period (one day).
-
2.
Implement an interpolation method based on splines approximation over a time partition \(k_{i} , i = 1:N_{i}\) based on \(y\left( {kT} \right)\) that generates a new vector \(y_{i} \left( {k_{i} T_{i} } \right)\) with \(T_{i}\) the new interpolating period.
-
3.
Using the new information \(y_{i} \left( {k_{i} T_{i} } \right)\), define the performance index for the modeling strategy defined as
$$J = \sum\limits_{i = 1}^{{N_{i} }} {\left( {y\left( {k_{i} T_{i} } \right) - F_{i} \left( {\widehat{\mu }_{\max } ,\widehat{\lambda }} \right)} \right)^{2} }$$where \(F\left( {\mu_{max} ,\lambda } \right)\) is any of the selected models in Table 2 evaluated at the movement \(k_{i}\).
-
4.
Based on the Matlab regression toolbox, the application of the Levenberg–Marquardt yields to define the evolution of the estimated parameters \(\left( {\hat{\mu }_{max} ,\hat{\lambda }} \right)\) in the model which are defined as
$$\begin{array}{*{20}c} {\hat{\mu }_{{max,\left( {i + 1} \right)}} = \hat{\mu }_{max,\left( i \right)} + \left[ {\mu I + S_{{\hat{\mu }_{max} }}^{T} S_{{\hat{\mu }_{max} }} } \right]^{ - 1} S_{{\hat{\mu }_{max} }}^{T} \left( {\mathop{y}\limits^{\rightharpoonup} - \mathop{F}\limits^{\rightharpoonup} \left( {\hat{\mu }_{max} ,\hat{\lambda }} \right)} \right)} \\ {\hat{\lambda }_{{\left( {i + 1} \right)}} = \hat{\lambda }_{\left( i \right)} + \left[ {\mu I + S_{{\hat{\lambda }}}^{T} S_{{\hat{\lambda }}} } \right]^{ - 1} S_{{\hat{\lambda }}}^{T} \left( {\mathop{y}\limits^{\rightharpoonup} - \mathop{F}\limits^{\rightharpoonup} \left( {\hat{\mu }_{max} ,\hat{\lambda }} \right)} \right)} \\ \end{array}$$where \(\hat{\mu }_{{max,\left( {i + 1} \right)}}\) and \(\hat{\lambda }_{{\left( {i + 1} \right)}}\) are the estimated values at the upcoming moment of the parameters of interest, \(\mu\) is a selected positive scalar, \(\mathop{y}\limits^{\rightharpoonup}\) is the vector made of the measurements \(y_{i} \left( {k_{i} T_{i} } \right)\) while \(F_{i} \left( {\hat{\mu }_{max} ,\hat{\lambda }} \right)\) is the corresponding vector made with the values of \(F_{i} \left( {\hat{\mu }_{max} ,\hat{\lambda }} \right)\). The functions \(S_{{\hat{\mu }_{max} }}\) and \(S_{{\hat{\lambda }}}\) are the derivatives of \(J\) with respect to \(\hat{\mu }_{max}\) and \(\hat{\lambda }\).
-
5.
The evolution of the algorithms presented in the step 4 allows to estimate the parameters under study, that is
$$\hat{\mu }_{max}^{*} = \hat{\mu }_{{max,\left( {N_{i} + 1} \right)}}, \; \text{and} \; \hat{\lambda }^{*} = \hat{\lambda }_{{\left( {N_{i} + 1} \right)}},$$
For the election of the primary model that best described growth, the squared errors of each model were compared. The model that showed the lowest mean quadratic errors (Ross 1996) was chosen for further statistical analysis. Notice that this strategy allowed not only comparing the obtained modeling results in this study, but compare them with respect to other modeling effort of morel growth experiments.
Statistical analysis
Growth differences among different culture media, strains and models including maximum growth rate (μmax) and lag phase (λ) were compared using the multivariate analysis of variance (MANOVA). When statistical differences were found, the Duncan Test with α = 0.05 was applied.
Results
MEA-coconut media resulted in the highest mycelial growth
With the purpose of selecting a culture broth that promotes the highest growth rate (among the evaluated media) of morel mycelium, the reference strain M. esculenta (for reference purposes) and the wild isolated FRE-3C (Table 1) were cultivated in seven different culture media (agar, agar-lactose, agar-coconut, agar-lactose-coconut, MEA, MEA-lactose and MEA-coconut).
Morel growth was estimated using the maximum radius of mycelium distribution in the Petri dish, measured every day. Qualitative characteristics as color, mycelial density and presence of aerial or submerged mycelium were also described. No effect of strain type (M. esculenta and wild morel isolate FRE-3C) on growth was observed (p < 0.05); therefore both strains were considered as homogeneous group to assess the effect of culture media on mycelial growth. Morel strains (M. esculenta and wild morel isolate FRE-3C) cultivated in MEA-coconut showed the highest growth (Fig. 1). The lowest growth was registered in agar and in agar-lactose cultures (p < 0.05). As MEA-coconut media resulted in the best mycelial growth (Fig. 1), this media was chosen to cultivate all other wild strains (isolates FRE-5E, FRE-6F, FRE-I, FRE-L and FRE-M) for the second part of the growth experiments.
Morphology of morel mycelia changed depending on the culture media. Cultures of agar and agar-lactose grew disperse and hyphae were hyaline. On the other hand, cultures grown in MEA, MEA-lactose and MEA-coconut showed slight brown or brown pigmentations. It should be noticed that sometimes strains showed a slight brown pigmentation and over time turned into brown or dark brown (Table 3, Fig. 2). The largest mycelial density and aerial mycelium were registered in MEA-coconut cultures (Table 3, Figs. 2, 3).
Morphological differences among the rest of the isolates were also analyzed. Wild isolates FRE-5E, FRE-6F, FRE-L and FRE-M showed abundant plumose aerial mycelium and slight brown pigmentation whereas M. esculenta as well as isolates FRE-3C and FRE-I showed the smaller amounts of aerial mycelium (Table 3, Fig. 3).
All cultures containing coconut water showed the presence of sclerotia after nine to twelve days of cultivation, excepting M. esculenta cultures which showed only young sclerotia (Volk and Leonard 1990) on MEA-coconut. Isolates FRE-L and FRE-M exhibited presence of micro-sclerotia (< 0.5 mm; Buscot 1993) at the borders of the Petri dish. Isolates FRE-3C and FRE-I exhibited micro-sclerotia around the center and in some cases in a certain area of the Petri dish. Late sclerotia (> 0.5 mm; Buscot 1993) appeared in cultures of isolates FRE-5E and FRE-6F (Table 3, Fig. 3).
This study shows for the first time the presence of sclerotia in all wild morel isolates cultures containing coconut water, excepting M. esculenta cultures in which only young sclerotia (Volk and Leonard 1990) were observed on MEA-coconut.
Baranyi’s primary model fit the best description of morels mycelial growth
With the aim of characterizing the morel mycelium growth curve, linear, Baranyi’s and exponential models were considered in this study. By using these mathematical models, it was possible to estimate kinetic parameters including lag phase (λ) and maximum specific growth rate (µmax) of each cultured strain/isolate. All values of μmax and λ for each model are listed in Table S1 of Additional file 1. The lowest values of λ were obtained by the linear model while the largest ones were obtained by logistic and Baranyi’s models (p < 0.05). The largest values of μmax were obtained using the logistic model and the lowest values were obtained by the linear model (p < 0.05). Moreover, logistic model tends to overestimate μmax and, in some cases the predicted values of A (upper asymptotic value) were above of what is biologically possible to expand for a fungi at growing phase. Despite logistic model gave accurate estimations of final diameter of morel colonies and showed a satisfactory fitting quality, Baranyi’s model was chosen for further analysis because it showed the lowest mean quadratic errors (Ross 1996).
Morel kinetic growth parameters are influenced by culture media
To elucidate how morel mycelium growth was influenced by culture media, kinetic parameters obtained by Baranyi’s model (μmax and λ) of M. esculenta and isolate FRE-3C cultivated in different culture media, were compared by multivariate analysis of variance (MANOVA) and Duncan pos hoc analysis (α = 0.05). Values of lag phase (λ) for both strains did not show differences related to culture media (Fig. 4a, p < 0.05). On the other hand, maximum growth rate was influenced by the selected culture broth. The lowest values of μmax were obtained in agar and agar-lactose cultures and highest ones were obtained in MEA-coconut cultures. In addition, cultures such as agar, agar lactose and EMA increased the values of μmax under presence of coconut water (Fig. 4b, p < 0.05).
Kinetic growth parameters vary according to the morel species
For the second stage of growing experiments, this study assesses if kinetic growth parameters (μmax and λ) were influenced by morel species. Wild morel isolates (FRE-5E, FRE-6F, FRE-I, FRE-L and FRE-M; Table 1) were cultivated in MEA-coconut (the culture media with the highest growth performance) and growth curves were fitted by primary modeling (Additional file 1: Table S1). Baranyi’s model growth kinetic values obtained for all the strains cultured in MEA-coconut (including M. esculenta CDBB-H-482 and isolate FRE-3C) were considered into the multivariate analysis of variance (MANOVA) and Duncan pos hoc analysis (α = 0.05). Wild isolate FRE-3C showed the higher lag phase (2.41 ± 0.04 days), followed by M. esculenta (2.1 ± 0.05 days). Isolates FRE-L, FRE-M, FRE-5E, FRE-6F showed similar values of λ (1.54 ± 0.24; 1.59 ± 0.28; 1.61 ± 0.01; 1.66 ± 0.02 days respectively, Fig. 5a).
a Lag phase of M. esculenta CDBB-H-482 and Morchella sp. wild isolates (FRE-3C, FRE-5E, FRE-6F, FRE-I, FRE-L, FRE-M) cultivated in MEA-coconut. Different letters indicate significant differences according to Duncan test (p < 0.05, n = 10). b Growth rates of Morchella spp. wild strains cultivated in MEA-coconut. Different letters indicate significant differences according to Duncan test (p < 0.05, n = 10)
Regarding growth rates estimations, isolate FRE-I exhibited the lowest values of μmax (10.37 ± 0.58), whereas isolates FRE-L and FRE-M showed the highest values (33.53 ± 0.46; 33.40 ± 0.39; Fig. 5b; p < 0.05). Although isolate FRE-I did not have a long lag phase in comparison with isolate FRE-3C and M. esculenta, its growth rate was the slowest, which makes that this strain took the longest time to grow.
Discussion
Coconut water increase mycelial growth rate.
In the present study is proposed a novel culture media formulation for morels based on coconut water. According to the modeling outcomes, coconut water used as culture media supplement yields augmented mycelial growth rate of morels. Coconut water is a complex matrix, whose composition varies depending on the maturity stage, species variety and the site of cultivation. This complex mixture has been extensively used as a growth-promoting element on in vitro plant tissue cultures (Winarto and da Silva 2015; Prando et al. 2014; Prades et al. 2012; Peixe et al. 2007). Its use during mushroom cultivation is not so popular, but it has been successfully used for cultivating Pleurotus djamor, P. salmoneostramineus, Ganoderma lucidum and Lentinus sp. (Zurbano et al. 2017; Kalaw et al. 2016; Jacob et al. 2015; Magday et al. 2014). Although the use of coconut water has not been fully contemplated for mushroom cultivation, it is considered as an important element during domestication of wild fungi (Kalaw et al. 2016; Magday et al. 2014), now including morels.
Among the components of coconut water, sugars, minerals, free amino acids and growth promoting factors are considered those that makes it a suitable growth medium for microorganisms, plants and mushrooms (Jacob et al. 2015; Prando et al. 2014; Prades et al. 2012). Regarding sugars, sucrose, sorbitol, glucose and fructose are present in larger proportions in coconut water. Minor carbohydrates are galactose, xylose and mannose (Prades et al. 2012; Yong et al. 2009). Notice that sugar proportion varies depending on the maturity stages of coconut. The coconut water used in this study (6 or 7 month old) has a sugar content that varies from 2.7 to 7 g per 100 mL of water (Prades et al. 2012). Such variations may affect the performance of a coconut-based culture media or the reproducibility of a specific response such as fungal growth. During morel cultivation, the proportion of sugars is an important factor to consider. There are reports demonstrating that a combination of sugars not always leads to increasing growth rate (Winder 2006). Sugars like glucose and lactose reduce growth rate when combined with other sugars. Otherwise, culture broths containing sucrose result into an enhancement of growth velocity (Winder 2006). Although the wide variety of sugars and nutrients present in coconut water, when coconut water was combined with lactose or malt extract, an enhancement of growth was observed. Thus, the use of the combined MEA-coconut culture media enhances growth rate and results in a production of abundant vigorous mycelium.
Regarding mineral content, potassium is present in a major proportion in coconut water. In a lesser amount are calcium, magnesium, iron and zinc (Tan et al. 2014; Prades et al. 2012). Dulay et al. (2020) evaluated the effect of mineral salts on mycelial growth of three Lentinus species. Cultures supplemented with potassium and magnesium salts supported efficiently mycelial growth. Since mineral nutrition is an important factor to consider during morel mycelial growth (Liu et al. 2015), apparently coconut water is supplying required mineral for growth in the form of organic complexes (Alchoubassi et al. 2021) that may be easily taken up by morel mycelium.
Aside of sugars or minerals, phytohormones are one of the most important components of coconut water (Prades et al. 2012; Yong et al. 2009; Ge et al. 2005). Growth regulators in coconut water comprise cytokinins (zeatin-O-glucoside, dihydrozeatin-O-glucoside, kinetin, ZMP -trans-zeatin riboside 5’-monophosphate-), gibberellins (GA1 and GA3), auxins (IAA: indole-3-acetic acid) and abscisic acid (Prades et al. 2012; Yong, et al. 2009). The function of phytohormones has been extensively studied in plants, but their role on mushrooms growth is scarce even when some fungi produce phytohormones themselves (Vedenicheva et al. 2016; Barker and Tagu 2000; Dua and Jandaik 1979). In the case of cytokinins, remains unknown whether these hormones originated in fungi, plants or in both (Barker and Tagu 2000). In plants, cytokinins are involved in cell division, nutrient uptake, stimulation of the activity of shoots and meristems, seed germination, retard leaf senescence and they also participate in stress regulation (Li et al. 2020; Yong et al. 2009). Even cytokinins are produced endogenously in Fungi; research efforts have been only focused on studying their role during plant-pathogen interaction (Vedenicheva et al. 2016; Pozo et al. 2014; Walters and McRoberts 2006). Recently Vedenicheva et al. (2016) reported endogenous production of cytokinins and Dulay et al. (2020) reported the influence of phytohormones on Lentinus mycelial growth. The possibility that observed enhancement of morel mycelia growth could be a consequence of cytokinins or to other phytohormones in coconut water deserves further study. Additional investigations are needed to elucidate the functions of phytohormones on mushroom metabolism, including their role on growth and fructification.
Coconut water promotes sclerotia formation.
Sclerotia formation during morel cultivation is highly sought but not often accomplished. Even though sclerotia formation process is still unrevealed; several efforts have been made to induce it in pure cultures (Guler and Ozkaya 2009; Winder 2006; Buscot 1993; Amir et al. 1992). Recently Liu et al. (2018) found that low concentrations of hydrogen peroxide increase sclerotia production, but high concentrations resulted in a low sclerotia production and the authors suggested that reactive oxygen species (ROS) play an important role in signaling more than creating cellular stress. Although composition of coconut endosperm is a complex matrix, its properties as inductor of cell division and cell differentiation are known (Prades et al. 2012; Yong et al. 2009). In this case, it is unknown which component of coconut water is promoting sclerotia production, but the use of the coconut endosperm may be an alternative to ensure their production during morel cultivation.
Mycelial morphology
As expected, morel mycelial morphology varied accordingly with the culture media and it was described comparatively with respect to previously reported by Winder (2006). Among the different culture media, the morphology which is considered as typical for morel mycelia (He et al. 2015) was observed in MEA, MEA-lactose and MEA-coconut cultures. Baran and Boron (2017) characterized the morphology of M. deliciosa and M. esculenta, but the differences between both strains were barely visible. Herein, evident morphological differences among wild morel strains enrich the knowledge about the variation of morel mycelia depending on the culture media composition or isolates.
Baranyi’s primary model is a valuable tool to assess mycelial growth
Although mathematical models were initially used to describe population growth, nowadays it is a useful tool to predict growth of pathogen moulds in food industry (Marín et al. 2008; Baty and Delignette-Muller 2004). Despite primary models provide valuable information, they are not commonly used to assess growth of edible mushrooms. Regarding morel characterization, growth is usually reported in terms of radial growth and kinetic parameters are not estimated.
Among the fitted models, linear model produces accurate predictions of growth, but it does not contemplate the lag phase which reduces the representativeness of the model for mycelium growth. Conversely, Baranyi’s model contemplates the lag phase because it has an adjustment function that delays exponential growth, so this phase can be better described by this model (Baty and Delignette-Muller 2004). This study takes advantage of primary models that can be a useful tool to assess optimization of morel mycelial growth. By using this tool, it could be possible to select strains with the most convenient kinetic parameters for the next stages of cultivation.
Variation of kinetic growth parameters according to the morel species
Herein, interspecific differences on kinetic growth parameters (λ and µmax) were shown for the first time on morels. According to Buchanan and Cygnarowicz (1990), lag phase comprises the period were growth slows down. During this period, diverse physiological processes took place with the aim of providing an adaptation to the surrounding growing environment. Valenzuela-Cobos et al. (2017) fitted growth of P. ostreatus, P. djamor and Lentinula edodes by using the Gompertz model and a nonlinear model. The values of λ ranged from 0.41 to 2.74 days. Such values are similar to those obtained in the present study (1.54 ± 0.24−2.41 ± 0.04 days), so the adaptation period is similar among morels and the Basidiomycetes above mentioned.
Valenzuela-Cobos et al. (2017) reported µmax values for P. ostreatus, P. djamor and L. edodes in a range from 0.44 to 1.27 days−1 for the modified Gompertz model and 0.26 to 1.69 day−1 by using the nonlinear model. The values of µmax obtained for morels are one order of magnitude superior (10.37 ± 0.58 to 40 ± 0.39 mm d−1; Fig. 5b) to those reported by Valenzuela-Cobos et al. (2017). Notice that morel mycelium is considered a fast growing mycelium. Despite its rapid growth, morel mycelium is very susceptible and stops growing when there is a lack of nutrients or a competitor (Pilz et al. 2007). As well, in nature morel mycelium seems to grow better and fruit in disturbed areas (Loizides 2017; Loizides et al. 2015; Pilz et al. 2004). For these reasons it could be considered as a pioneer species of secondary succession. Pioneers of secondary succession are described as fast growth species that first colonize disturbed nutrient rich habitats where competition is reduced (Dalling 2008). The faster growing attribute of morels can be of great benefit during its artificial cultivation, but its susceptibility to competitors should be considered.
The results presented in this study demonstrate that using coconut water during morel cultivation and domestication may be an encouraging cheap alternative to produce dense good quality mycelium and promote sclerotia formation. The growing effect of coconut water was characterized not only by observational subjective analysis but using the variations of parameters corresponding to three different nonlinear models. A robust parametric modeling strategy allows the effective characterization of morels growth influenced by the presence of coconut water in the culture broth. A feasible explanation regarding which components of the water could be responsible of growth improvement is also given in this study. Even coconut is a complex matrix and it was not possible to determine which components promoted the observed growth enhancement and sclerotia formation, the results obtained in this study highlight the need for further investigations regarding to the influence of phytohormones (like cytokinins) on growth metabolism and fructification of morel mycelia.
Availability of data and materials
All data generated or analyzed during this study are available from the corresponding author on reasonable request.
References
Alchoubassi G, Kinska K, Bierla K, Lobinski R, Szpunar J (2021) Speciation of essential nutrient trace elements in coconut water. Food Chem 339:12760. https://doi.org/10.1016/j.foodchem.2020.127680
Amir R, Levanon D, Hadar Y, Chet I (1992) Formation of sclerotia by Morchella esculenta: relationship between media composition and turgor potential in the mycelium. Mycol Res 96(11):943–948. https://doi.org/10.1016/S0953-7562(09)80595-9
Amir R, Levanon D, Hadar Y, Chet I (1993) Morphology and physiology of Morchella esculenta during sclerotial formation. Mycol Res 97(6):683–689. https://doi.org/10.1016/S0953-7562(09)80148-2
Amir R, Steudle E, Levanon D, Hadar Y, Chet I (1995) Turgor changes in Morchella esculenta during translocation and sclerotial formation. Exp Mycol 19:129–136. https://doi.org/10.1006/emyc.1995.1015
Baran J, Boron P (2017) Two species of true morels (the genus Morchella, Ascomycota) recorded in the Ojców National Park (south Poland). Acta Mycol 52(1):1094. https://doi.org/10.5586/am.1094
Barker SJ, Tagu D (2000) The roles of auxins and cytokinins in mycorrhizal symbioses. J Plant Growth Regul 19:144–154. https://doi.org/10.1007/s003440000021
Baty F, Delignette-Muller M-L (2004) Estimating the bacterial lag time: which model, which precision? Int J Food Microbiol 91:261–277. https://doi.org/10.1016/j.ijfoodmicro.2003.07.002
Brock TD (1951) Studies on the nutrition of Morchella esculenta Fries. Mycologia 43:402–422. https://doi.org/10.1080/00275514.1951.12024142
Buchanan RL, Cygnarowicz ML (1990) A mathematical approach toward defining and calculating the duration of the lag phase. Food Microbiol 7:237–240. https://doi.org/10.1016/0740-0020(90)90029-H
Buscot F (1993) Mycelial differentiation of Morchella esculenta in pure culture. Mycol Res 97(2):136–140. https://doi.org/10.1016/S0953-7562(09)80234-7
Dalling JW (2008) Pioneer species. Encyclopedia Ecol. https://doi.org/10.1016/B978-0-444-63768-0.00534-5
Du XH, Zhao Q, Yang LZ (2015) A review on research advances, issues and perspectives of morels. Mycology 6(2):78–85. https://doi.org/10.1080/21501203.2015.1016561
Dua IS, Jandaik CL (1979) Cytokinins in two cultivated edible mushrooms. Sci Hortic 10(3):301–304. https://doi.org/10.1016/0304-4238(79)90086-4
Dulay RMR, Cabrera EC, Kalaw SP, Reyes RG, Hou CT (2020) Nutritional requirements for mycelial growth of three Lentinus species from Philippines. Biocatal Agric Biotechnol 23:101506. https://doi.org/10.1016/j.bcab.2020.101506
El-Gharabawy HM, El-Fallal AA, El-Sayed KAA (2019) Description of a yellow morel from Egypt using morphological and molecular tools. Nova Hedwigia 109(1):95–110. https://doi.org/10.1127/nova_hedwigia/2019/0535
Ge L, Yong JWH, Goh NK, Chia LS, Tan SN, Ong ES (2005) Identification of kinetin and kinetin riboside in coconut (Cocos nucifera L.) water using a combined approach of liquid chromatography–tandem mass spectrometry, high performance liquid chromatography and capillary electrophoresis. J Chromatogr B 829(1–2):26–34. https://doi.org/10.1016/j.jchromb.2005.09.026
Georgiou CD, Patsoukis N, Papapostou I, Zervoudakis G (2006) Sclerotial metamorphosis in filamentous fungi is induced by oxidative stress. Integr Comp Biol 46(6):691–712. https://doi.org/10.1093/icb/icj034
Goldway M, Amir R, Goldberg D, Hadar Y, Levanon D (2000) Morchella conica exhibiting a long fruiting season. Mycol Res 104(8):1000–1004. https://doi.org/10.1017/S0953756200002598
Guler P, Ozakaya EG (2008) Sclerotial structures of Morchella conica in agar media with different carbohydrates. Acta Aliment 37(3):347–357. https://doi.org/10.1556/AAlim.2008.0001
Guler P, Ozkaya EG (2009) Morphological development of Morchella conica mycelium on different agar media. J Environ Biol 30(4):601–604
Guzman G, Tapia F (1998) The known morels in Mexico, a description of a new blushing species, Morchella rufobrunnea and new data on M. guatemalensis. Mycologia 90(4):705–714. https://doi.org/10.1080/00275514.1998.12026960
He P, Cai Y, Liu S, Li H, Huang L, Liu E (2015) Morphological and ultrastructural examination of senescence in Morchella elata. Micron 78:79–84. https://doi.org/10.1016/j.micron.2015.07.010
Hervey A, Bistis G, Leong I (1978) Cultural studies of single ascospore isolates of Morchella esculenta. Mycologia 70(6):1269–1274. https://doi.org/10.1080/00275514.1978.12020350
Jacob JKS, Kalaw SPK, Reyes RG (2015) Mycelial growth performance of three species of Pleurotus on coconut water gelatin. Curr Res Environ Appl Mycol 5(3):263–268. https://doi.org/10.5943/cream/5/3/910.5943/cream/5/3/9
Kalaw SP, Alfonso DO, Dulay RMR, De Leon AM, Undan JQ, Undan JR, Reyes RG (2016) Optimization of culture conditions for secondary mycelial growth of wild macrofungi from selected areas in Central Luzon, Philippines. Curr Res Environ Appl Mycol 6(4):277–287. https://doi.org/10.5943/cream/6/4/5
Kanwal HK, Reddy MS (2012) The effect of carbon and nitrogen sources on the formation of sclerotia in Morchella spp. Ann Microbiol 62:165–168. https://doi.org/10.1007/s13213-011-0241-6
Li S-M, Zheng H-X, Zhang X-S, Sui N (2020) Cytokinins as central regulators during plant growth and stress response. Plant Cell Rep 40:271–282. https://doi.org/10.1007/s00299-020-02612-1
Liu H, Xu J, Li X, Zhang Y, Yin A, Wang J, Long Z (2015) Effects of microelemental fertilizers on yields, mineral element levels and nutritional compositions on the artificially cultivated Morchella conica. Sci Hortic 189:86–93. https://doi.org/10.1016/j.scienta.2015.03.047
Liu Q, Husheng M, Zhang Y, Dong C (2017) Artificial cultivation of true morels: current state, issues and perspectives. Crit Rev Biotechnol 38(2):259–271. https://doi.org/10.1080/07388551.2017.1333082
Liu Q, Zhao Z, Dong H, Dong C (2018) Reactive oxygen species induce sclerotial formation in Morchella importuna. Appl Microbiol Biotechnol 102:7997–8009. https://doi.org/10.1007/s00253-018-9104-4
Loizides M (2017) Morels: the story so far. Field Mycol 18(2):42–53. https://doi.org/10.1016/j.fldmyc.2017.04.004
Loizides M, Alvarado P, Clowez P, Moreau P-A, de la Osa LR, Palazón A (2015) Morchella tridentina, M. rufobrunnea, and M. kakiicolor: a study of three poorly known Mediterranean morels, with nomenclatural updates in section Distantes. Mycol Prog 14(3):12–18. https://doi.org/10.1007/s11557-015-1030-6
Magday JC, Bungihan ME, Dulay RMR (2014) Optimization of fruiting body of Philippine wild strain of Ganoderma lucidum. Curr Res Environ Appl Mycol 4(2):162–172. https://doi.org/10.5943/cream/4/2/4
Marín S, Cuevas D, Ramos AJ, Sanchis V (2008) Fitting of colony diameter and ergosterol as indicators of food borne mould growth to known growth models in solid medium. Int J Food Microbiol 121:139–149. https://doi.org/10.1016/j.ijfoodmicro.2007.08.030
Mihail JD, Bruhn JN, Bonello P (2007) Spatial and temporal patterns of morel fruiting. Mycol Res 111(3):339–346. https://doi.org/10.1016/j.mycres.2007.01.007
Ower RD (1982) Notes on the development of the morel ascocarp. Mycologia 74:142–144. https://doi.org/10.1080/00275514.1982.12021480
Ower RD, Mills GL, Malachowski JA, Inventors. Neogen Corporation assignee (1986) Cultivation of Morchella. United States Patent US 4, 594, 809. Jun 17
Peixe A, Raposo A, Lourenço R, Cardoso H, Macedo E (2007) Coconut water and BAP successfully replaced zeatin in olive (Olea europaea L.) micropropagation. Sci Hortic 113:1–7. https://doi.org/10.1016/j.scienta.2007.01.011
Pilz D, Weber NS, Carter CM, Parks CK, Molina R (2004) Productivity and diversity of morel mushrooms in healthy, burned, and insect damaged forests of northeastern Oregon. For Ecol Manag 198:367–386. https://doi.org/10.1016/j.foreco.2004.05.028
Pilz D, Mc Lain R, Alexander S, Villarreal-Ruiz L, Berch S, Wurtz TL, Parks CG, McFarlane E, Baker B, Molina R, Smith JE (2007) Ecology and management of morels harvested from the forests of Western North America. General Technical Report PNW-GTR-710. US Department of Agriculture, Forest Service, Pacific Northwest Research Station. doi.org/https://doi.org/10.2737/PNW-GTR-710
Pozo MJ, López-Ráez JA, Azcón-Aguilar C, García-Garrido JM (2014) Phytohormones as integrators of environmental signals in the regulation of mycorrhizal symbioses. New Phytol 205:1431–1436. https://doi.org/10.1111/nph.13252
Prades A, Dornier M, Diop N, Pain J-P (2012) Coconut water uses, composition and properties: a review. Fruits 67:87–107. https://doi.org/10.1051/fruits/2012002
Prando MAS, Chiavazza P, Faggio A, Contessa C (2014) Effect of coconut water and growth regulator supplements on in vitro propagation of Corylus avellana L. Sci Hortic 171:91–94. https://doi.org/10.1016/j.scienta.2014.03.052
Raut KJ, Upadhyaya J, Raghavan V, Adhikari M, Bhushal S, Sainju PS, Gurmachhan CM, Giri A, Bhatt LR (2019) Trade and conservation of morel mushrooms in Nepal. IJNREM 4(6):183–187. https://doi.org/10.11648/j.ijnrem.20190406.14
Ross T (1996) Indices for performance evaluation of predictive models in food microbiology. J Appl Bacteriol 81(5):501–508. https://doi.org/10.1111/j.1365-2672.1996.tb03539.x
Shashidhar GM, Sravan Kumar S, Giridhar P, Manohar B (2017) Antioxidant and colesterol esterase inhibitory properties of supplementation with coconut water in submerged cultivation of the medicinal Chinese caterpillar mushroom, Ophicordyceps sinensis CS1197 (Ascomycetes). Int J Med Mushrooms 19(4):337–345. https://doi.org/10.1615/IntJMedMushrooms.v19.i4.40
Tan T-C, Cheng L-H, Bhat R, Rusul G, Easa AM (2014) Composition, physicochemical properties and thermal inactivation kinetics of polyphenol oxidase and peroxidase from coconut (Cocos nucifera) water obtained from immature, mature and overly-mature coconut. Food Chem 142:121–128. https://doi.org/10.1016/j.foodchem.2013.07.040
Valenzuela-Cobos JD, Durán PE, Villanueva AR, Garín AME, Sánchez HA, Leal LH, Valencia del Toro G (2017) Production of hybrid strains among Pleurotus and Lentinula and evaluation of their mycelial growth kinetics on malt extract agar and wheat grain using the Gompertz and Hill models. Emir J Food Agric 29(12):927–935. https://doi.org/10.9755/ejfa.2017.v29.i12.1563
Vedenicheva NP, Al Maali GA, Mytropolska NY, Mykhaylova OB, Bisko NA, Kosakivska IV (2016) Endogenous cytokinins in medicinal basidiomycetes mycelial biomass. Biotechnol Acta 9(1):55–63. https://doi.org/10.15407/biotech9.01.055
Volk TJ, Leonard TJ (1989) Physiological and environmental studies of sclerotium formation and maturation in isolates of Morchella crassipes. Appl Environ Microbiol 55(12):3095–3100. https://doi.org/10.1128/AEM.55.12.3095-3100.1989
Volk TJ, Leonard TJ (1990) Cytology of the life-cycle of Morchella. Mycol Res 94(3):399–406. https://doi.org/10.1016/S0953-7562(09)80365-1
Walters DR, McRoberts N (2006) Plants and biotrophs: a pivotal role for cytokinins? Trends Plant Sci 11(12):581–586. https://doi.org/10.1016/j.tplants.2006.10.003
Winarto B, da Silva JAT (2015) Use of coconut water and fertilizer for in vitro proliferation and plantlet production of Dendrobium ‘Gradita 31.’ In Vitro Cell Dev Biol Plant 51:303–314. https://doi.org/10.1007/s11627-015-9683-z
Winder RS (2006) Cultural studies of Morchella elata. Mycol Res 110:612–623. https://doi.org/10.1016/j.mycres.2006.02.003
Yong JWH, Ge L, Ng YF, Tam SN (2009) The chemical composition and biological properties of coconut (Cocos nucifera L.) water. Molecules 14:5144–5164. https://doi.org/10.3390/molecules14125144
Zurbano LY, Bellere AD, Savilla LC (2017) Mycelial growth, fruiting body production and proximate composition of Pleurotus djamor on different substrate. CLSU Int J Sci Technol 2(1):20–30. https://doi.org/10.22137/ijst.2017.v2n1.03
Zwietering MH, Jongenburger I, Rombouts FM, VantRiet K (1990) Modeling of bacterial growth curve. Appl Environ Microbiol 56:1875–1881. https://doi.org/10.1128/AEM.56.6.1875-1881.1990
Acknowledgements
The authors would like to thank the Instituto Politécnico Nacional.
Funding
The authors would like to thank the Instituto Politécnico Nacional research projects SIP20200412 and SIP20210805 for the financial support.
Author information
Authors and Affiliations
Contributions
FRE and GVT conceived and designed research. SS and FRE conducted field research and sample collection activities. FRE and CRMG conducted experiments. IC contributed to analysis and software tools. FRE wrote original draft. GVT, HLL, SS, MEGA and IC provided the resources and contribute to analyze data. All authors contributed to reviewing and editing the original draft. All authors read and approved the final manuscript.
Corresponding author
Ethics declarations
Ethical approval and consent to participate
This article does not contain any studies with human participants or animals performed by any of the authors.
Consent for publication
All authors declare that agree with submit the manuscript to AMB Express.
Competing interests
Author Fabiola Rodríguez Evangelista declares that she has no conflict of interest. Author Isaac Chairez declares that he has no conflict of interest. Author Sigfrido Sierra declares that he has no conflict of interest. Author Hermilo Leal Lara declares that he has no conflict of interest. Author César Ramiro Martínez González declares that he has no conflict of interest. Author María Eugenia Garín Aguilar declares that she has no conflict of interest. Author Gustavo Valencia del Toro declares that he has no conflict of interest.
Additional information
Publisher's Note
Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
Supplementary Information
Additional file 1:
Table S1. Growth rates (μmax, mm d-1) and lag phases (λ, days) of morel wild strains cultivated in different culture media according to linear model, Baranyi’s model and Logistic model (n=10).
Rights and permissions
Open Access This article is licensed under a Creative Commons Attribution 4.0 International License, which permits use, sharing, adaptation, distribution and reproduction in any medium or format, as long as you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons licence, and indicate if changes were made. The images or other third party material in this article are included in the article's Creative Commons licence, unless indicated otherwise in a credit line to the material. If material is not included in the article's Creative Commons licence and your intended use is not permitted by statutory regulation or exceeds the permitted use, you will need to obtain permission directly from the copyright holder. To view a copy of this licence, visit http://creativecommons.org/licenses/by/4.0/.
About this article
Cite this article
Evangelista, F.R., Chairez, I., Sierra, S. et al. A novel coconut-malt extract medium increases growth rate of morels in pure culture. AMB Expr 11, 167 (2021). https://doi.org/10.1186/s13568-021-01325-2
Received:
Accepted:
Published:
DOI: https://doi.org/10.1186/s13568-021-01325-2
Keywords
- Morchella
- Coconut water
- Cultivation
- Baranyi’s model
- Growth rate
